95
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FB807 1-469-324-21 FERRITE 0UH (US,CND,MX)
FB807 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US,CND,MX)
< FILTER >
FL801 1-518-767-21 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-366-45 IC NJU3713G(TE2)
IC802 6-700-112-01 IC MSM9202-05GS-KDR1
< JUMPER RESISTOR >
JR800 1-216-864-11 METAL CHIP 0 5% 1/16W
JR801 1-216-864-11 METAL CHIP 0 5% 1/16W
JR802 1-216-864-11 METAL CHIP 0 5% 1/16W
JR805 1-216-864-11 METAL CHIP 0 5% 1/16W
JR806 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q801 8-729-602-36 TRANSISTOR 2SA1602TP-1EF
< RESISTOR >
R805 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R810 1-216-809-11 METAL CHIP 100 5% 1/16W
R811 1-216-809-11 METAL CHIP 100 5% 1/16W
R812 1-216-809-11 METAL CHIP 100 5% 1/16W
R813 1-216-809-11 METAL CHIP 100 5% 1/16W
R814 1-216-841-11 METAL CHIP 47K 5% 1/16W
R839 1-216-864-11 METAL CHIP 0 5% 1/16W
R840 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
R845 1-216-833-11 METAL CHIP 10K 5% 1/16W
**************************************************************
1-681-999-13 FU 1179 BOARD
*************
< CAPACITOR >
C800 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C808 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C809 1-126-153-11 ELECT 22uF 20% 6.3V
< IC >
IC800 8-759-827-70 IC NJL64H400A-1 (g)
< RESISTOR >
R809 1-216-813-11 METAL CHIP 220 5% 1/16W
R815 1-216-805-11 METAL CHIP 47 5% 1/16W
R837 1-216-815-11 METAL CHIP 330 5% 1/16W
R838 1-216-805-11 METAL CHIP 47 5% 1/16W
R844 1-216-817-11 METAL CHIP 470 5% 1/16W
R849 1-216-819-11 METAL CHIP 680 5% 1/16W
R860 1-216-821-11 METAL CHIP 1K 5% 1/16W
R870 1-216-864-11 METAL CHIP 0 5% 1/16W
R871 1-216-864-11 METAL CHIP 0 5% 1/16W
R873 1-216-813-11 METAL CHIP 220 5% 1/16W
< ROTARY ENCODER/SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
S821 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD+)
S822 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD-)
S823 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S824 1-762-875-21 SWITCH, KEYBOARD (BAND)
S825 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
**************************************************************
1-682-003-13 HP 1179 BOARD
**************
< CAPACITOR >
C900 1-126-204-11 ELECT CHIP 47uF 20% 16V
C901 1-126-204-11 ELECT CHIP 47uF 20% 16V
C902 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C903 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C904 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
< FERRITE BEAD >
FB803 1-412-006-31 INDUCTOR 10UH (US,CND,MX)
FB803 1-469-144-21 FERRITE 0UH (EXCEPT US,CND,MX)
FB804 1-412-006-31 INDUCTOR 10UH (US,CND,MX)
FB804 1-469-144-21 FERRITE 0UH (EXCEPT US,CND,MX)
FB805 1-412-006-31 INDUCTOR 10UH (US,CND,MX)
FB805 1-469-144-21 FERRITE 0UH (EXCEPT US,CND,MX)
< JACK >
J900 1-566-891-21 JACK (PHONES)
< COIL >
L900 1-410-387-11 INDUCTOR CHIP 33uH (EXCEPT US,CND,MX)
L900 1-410-993-11 INDUCTOR CHIP 1uH (US,CND,MX)
L901 1-410-387-11 INDUCTOR CHIP 33uH (EXCEPT US,CND,MX)
L901 1-410-993-11 INDUCTOR CHIP 1uH (US,CND,MX)
L903 1-412-006-31 INDUCTOR 10uH (US,CND,MX)
L903 1-469-144-21 FERRITE 0uH (EXCEPT US,CND,MX)
L904 1-412-006-31 INDUCTOR 10uH (US,CND,MX)
L904 1-469-144-21 FERRITE 0uH (EXCEPT US,CND,MX)
< TRANSISTOR >
Q900 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q901 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
< RESISTOR >
R900 1-216-864-11 METAL CHIP 0 5% 1/16W
R901 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R902 1-216-864-11 METAL CHIP 0 5% 1/16W
R903 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R905 1-216-821-11 METAL CHIP 1K 5% 1/16W
R906 1-216-821-11 METAL CHIP 1K 5% 1/16W
**************************************************************
FP 1179 FU 1179 HP 1179
