96
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-4676-746-A I/O BOARD, COMPLETE (US,CND)
A-4729-822-A I/O BOARD, COMPLETE (E12,SP,EA)
A-4729-830-A I/O BOARD, COMPLETE (AUS)
A-4729-845-A I/O BOARD, COMPLETE (E32,MX)
*******************
< CAPACITOR >
C600 1-128-551-11 ELECT 22uF 20.00% 25V
C601 1-128-551-11 ELECT 22uF 20.00% 25V
C602 1-126-933-11 ELECT 100uF 20.00% 16V
C603 1-126-960-11 ELECT 1uF 20.00% 50V
C604 1-126-960-11 ELECT 1uF 20.00% 50V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C608 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C609 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C610 1-128-551-11 ELECT 22uF 20.00% 25V
C611 1-128-551-11 ELECT 22uF 20.00% 25V
C613 1-128-551-11 ELECT 22uF 20.00% 25V
C614 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C615 1-128-551-11 ELECT 22uF 20.00% 25V
C616 1-128-551-11 ELECT 22uF 20.00% 25V
C617 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C620 1-128-551-11 ELECT 22uF 20.00% 25V
C621 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C622 1-128-551-11 ELECT 22uF 20.00% 25V
C623 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C624 1-128-551-11 ELECT 22uF 20.00% 25V
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C626 1-128-551-11 ELECT 22uF 20.00% 25V
C627 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C628 1-126-933-11 ELECT 100uF 20.00% 16V
C630 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C631 1-128-551-11 ELECT 22uF 20.00% 25V
C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C661 1-126-964-11 ELECT 10uF 20.00% 50V
C662 1-126-964-11 ELECT 10uF 20.00% 50V
C671 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C672 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C700 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C701 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C705 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C706 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C708 1-126-933-11 ELECT 100uF 20.00% 16V
C712 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C713 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C720 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C721 1-124-261-00 ELECT 10uF 20% 50V
C722 1-126-157-11 ELECT 10uF 20% 16V
C724 1-125-972-61 ELECT 100uF 20.00% 16V
C725 1-124-234-00 ELECT 22uF 20% 16V
C727 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C728 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C730 1-125-972-61 ELECT 100uF 20.00% 16V
C731 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C732 1-125-972-61 ELECT 100uF 20.00% 16V
C733 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C734 1-124-234-00 ELECT 22uF 20% 16V
C735 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C737 1-124-261-00 ELECT 10uF 20% 50V
C738 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C739 1-216-864-11 METAL CHIP 0 5% 1/16W
C740 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C741 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C753 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C754 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C758 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C759 1-126-933-11 ELECT 100uF 20.00% 16V
C791 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C792 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C793 1-162-302-11 CERAMIC 0.0022uF 30.00% 16V
C795 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(US,CND)
C802 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C803 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
< CONNECTOR >
CN600 1-794-431-11 CONNECTOR, FFC/FPC 13P
CN601 1-779-297-11 CONNECTOR,FFC(LIF(NON-ZIF))29P
CN700 1-779-550-21 CONNECTOR,FFC(LIF(NON-ZIF))13P
* CN701 1-566-004-11 PIN, CONNECTOR (PC BOARD) 7P
< DIODE >
D601 8-719-056-85 DIODE UDZSTE-178.2B
D611 8-719-404-50 DIODE MA111-TX
D612 8-719-404-50 DIODE MA111-TX
< FERRITE BEAD >
FB601 1-469-324-21 FERRITE 0UH
FB611 1-469-324-21 FERRITE 0UH
FB612 1-469-324-21 FERRITE 0UH (US,CND)
FB612 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US,CND)
FB613 1-469-324-21 FERRITE 0UH (US,CND)
FB613 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT US,CND)
FB614 1-216-864-11 METAL CHIP 0 5% 1/16W
FB615 1-469-324-21 FERRITE 0UH
< IC >
IC600 8-759-385-76 IC MC14052 BDR2
IC601 8-759-646-52 IC KIA7805API
IC602 8-749-923-05 IC TORX178B (AUDIO 2 OPTICAL DIGITAL IN)
IC701 8-759-680-28 IC BA7666FS-E2
IC702 8-759-284-49 IC NJM2285V-TE2
< JACK >
J600 1-779-688-11 JACK, PIN 6P (AUDIO 1/AUDIO 2))
J700 1-815-748-21 JACK, PIN 2P (MONITOR OUT)
< COIL >
L600 1-216-295-91 SHORT CHIP 0
L601 1-469-525-91 INDUCTOR 10uH
L602 1-414-398-11 INDUCTOR 10uH
L603 1-414-398-11 INDUCTOR 10uH
L700 1-412-953-11 INDUCTOR 15uH
I/O
