Sony HCD-C450 - POWER Board Parts List

98
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< SWITCH >
S703 1-771-218-11 SWITCH, MICRO (MID IN)
S704 1-771-218-11 SWITCH, MICRO (IN)
**************************************************************
1-675-724-21 INIT/COUNT SW BOARD
********************
S705 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY) (INIT)
S706 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY) (COUNT)
**************************************************************
1-675-728-21 LOAD MOTOR BOARD
******************
< CAPACITOR >
C703 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C704 1-126-964-11 ELECT 10uF 20.00% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C712 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
* CN713 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D702 8-719-109-85 DIODE MTZJ-T-77-5.1B
< IC >
IC702 8-759-633-65 IC M54641L
< RESISTOR >
R703 1-249-411-11 CARBON 330 5% 1/4W
R704 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-675-725-21 OUT SW BOARD
*************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
CN715 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MID OUT)
S702 1-771-218-11 SWITCH, MICRO (LID)
S708 1-771-218-11 SWITCH, MICRO (OUT)
**************************************************************
A-4676-738-A POWER BOARD, COMPLETE (US,CND)
A-4729-814-A POWER BOARD, COMPLETE (AUS,E12,SP,EA)
A-4729-838-A POWER BOARD, COMPLETE (MX)
A-4729-840-A POWER BOARD, COMPLETE (E32)
***********************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
0C901 1-117-703-11 CERAMIC 0.0047uF 99% 250V
(US,CND,MX)
0C901 1-117-699-11 CERAMIC 0.001uF 99% 250V
(E32)
0C902 1-165-528-11 MYLAR 0.1uF 10 275V
0C903 1-162-290-31 CERAMIC 470PF 10% 50V
0C904 1-165-528-11 MYLAR 0.1uF 10 275V
0C905 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US,CND,MX)
0C905 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US,CND,MX)
0C906 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(US,CND,MX)
0C906 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US,CND,MX)
0C907 1-164-159-21 CERAMIC 0.1uF 50V
(US,CND,MX)
0C907 1-115-340-11 CERAMIC CHIP 0.22uF 10.00% 25V
(EXCEPT US,CND,MX)
0C908 1-113-920-11 CERAMIC 0.0022uF 20.00% 50V
(US,CND,MX)
0C908 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
(EXCEPT US,CND,MX)
C909 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(AUS,E12,E32,SP,EA)
C910 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(AUS,E12,E32,SP,EA)
C911 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
(AUS,E12,E32,SP,EA)
0C912 1-137-994-31 ELECT 820uF 20% 200V
(US,CND)
0C912 1-165-911-21 ELECT 390uF 20% 450V
(EXCEPT US,CND,MX)
0C913 1-136-203-11 FILM 10000PF 5.00% 630V
(US,CND,MX)
0C913 1-117-452-11 FILM 3300PF 5.00% 630V
(EXCEPT US,CND,MX)
0C914 1-126-967-11 ELECT 47uF 20.00% 50V
0C915 1-162-286-21 CERAMIC 220PF 10.00% 50V
(US,CND,MX)
0C915 1-162-292-31 CERAMIC 680PF 10% 50V
(EXCEPT US,CND,MX)
0C916 1-117-454-11 FILM 4700PF 5.00% 630V
(US,CND,MX)
0C916 1-125-772-51 CERAMIC 1500PF 10.00% 2KV
(EXCEPT US,CND,MX)
C917 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(US,CND,MX)
C918 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C919 1-115-789-11 ELECT 1000uF 20.00% 25V
C920 1-136-203-11 FILM 10000PF 5.00% 630V
(US,CND,MX)
C920 1-117-454-11 FILM 4700PF 5.00% 630V
(EXCEPT US,CND,MX)
C921 1-115-819-11 ELECT 2200uF 20.00% 35V
C922 1-128-560-11 ELECT 22uF 20.00% 100V
C923 1-115-819-11 ELECT 2200uF 20.00% 35V
C924 1-126-953-11 ELECT 2200uF 20.00% 35V
C925 1-126-160-11 ELECT 1uF 20% 50V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
LOAD MOTOR OUT SW POWERIN SW INIT/COUNT SW
