99
HCD-C450
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C926 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C927 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C928 1-126-926-11 ELECT 1000uF 20.00% 10V
C929 1-124-584-00 ELECT 100uF 20% 10V
C930 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C931 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C932 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C933 1-126-768-11 ELECT 2200uF 20.00% 16V
C936 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96MM PITCH) 2P
* CN902 1-564-321-21 PIN, CONNECTOR (3.96MM PITCH) 2P
* CN904 1-564-778-11 PLUG, CONNECTOR (2.5MM) 4P
* CN905 1-506-994-11 PIN, CONNECTOR (PC BOARD) 12P
(US,CND,MX)
< DIODE >
0D901 8-719-210-21 DIODE 11EQS04-TA1B
0D902 8-719-022-92 DIODE RBV-604 (US,CND,MX)
0D902 8-719-312-05 DIODE RBV-606 (EXCEPT US,CND,MX)
0D903 8-719-010-98 DIODE MTZJ-T-77-22A
0D904 8-719-110-61 DIODE MTZJ-T-77-24A
0D905 8-719-200-91 DIODE 11EQS10-TA1
0D906 8-719-200-91 DIODE 11EQS10-TA1
0D907 8-719-200-91 DIODE 11EQS10-TA1
0D908 6-500-071-01 DIODE SARS02-V1 (US,CND,MX)
0D908 8-719-080-26 DIODE SARS01V0 (EXCEPT US,CND,MX)
D909 8-719-312-08 DIODE FMB-G16L
D910 8-719-200-91 DIODE 11EQS10-TA1
D911 8-719-313-14 DIODE FML-22S
D912 8-719-110-42 DIODE MTZJ-T-77-15C
D913 8-719-404-50 DIODE MA111-TX
D914 8-719-210-21 DIODE 11EQS04-TA1B
D915 8-719-404-50 DIODE MA111-TX
D916 8-719-210-21 DIODE 11EQS04-TA1B
D917 8-719-200-82 DIODE 11ES2-NTA1B
D918 8-719-404-50 DIODE MA111-TX
< TERMINAL >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB901 1-412-473-21 INDUCTOR 0UH
< IC >
0IC901 8-749-017-79 IC STR-F6676
IC902 6-700-388-01 IC SE-B2
IC903 6-700-812-01 IC SI-8050JF
IC904 8-759-332-29 IC M51945BL
IC905 8-759-231-53 IC TA7805S (US,CND,MX)
IC905 8-759-450-47 IC BA05T (EXCEPT US,CND,MX)
IC906 6-700-813-01 IC SI-8033JF
IC907 8-759-390-72 IC TC4S584F(TE85R)
< COIL >
L901 1-424-860-11 INDUCTOR 10uH
L902 1-419-253-11 INDUCTOR 100uH
L903 1-419-253-11 INDUCTOR 100uH
L904 1-414-398-11 INDUCTOR 10uH
L905 1-414-398-11 INDUCTOR 10uH
L906 1-414-398-11 INDUCTOR 10uH
L907 1-414-398-11 INDUCTOR 10uH
L908 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0LF901 1-424-930-11 COIL, LINE FILTER (EXCEPT E32)
0LF901 1-428-906-11 COIL, LINE FILTER (E32)
LF902 1-424-930-11 COIL, LINE FILTER (AUS,E12,SP,EA)
LF902 1-428-906-11 COIL, LINE FILTER (E32)
< IC >
0PC901 8-749-019-04 IC TLP421
0PC902 8-749-019-04 IC TLP421
< TRANSISTOR >
0Q901 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
0Q902 8-729-140-04 TRANSISTOR 2SB1116A-TP-LK
0Q903 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q905 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q906 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q907 8-729-030-19 TRANSISTOR 2SB1640(TP)
Q908 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q909 8-729-027-49 TRANSISTOR DTC123EKA-T146
Q910 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q911 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q915 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
0R900 1-219-237-11 SOLID 3.3M 20% 1/2W
(US,CND,MX)
0R901 1-249-415-11 CARBON 680 5% 1/4W F
0R902 1-243-979-31 METAL OXIDE 0.1 5% 2W
(US,CND,MX)
0R902 1-216-361-31 METAL OXIDE 0.22 5% 2W
(EXCEPT US,CND,MX)
0R903 1-245-261-31 METAL OXIDE 0.12 5% 2W
(US,CND,MX)
0R903 1-245-277-31 METAL OXIDE 0.36 5% 2W
(E32)
0R903 1-245-266-31 METAL OXIDE 0.24 5% 2W
(AUS,E12,SP,EA)
0R904 1-247-881-00 CARBON 120K 5% 1/4W
0R905 1-249-439-11 CARBON 68K 5% 1/4W
0R906 1-249-424-11 CARBON 3.9K 5% 1/4W F
0R907 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R908 1-215-878-00 METAL OXIDE 33K 5% 1W
(US,CND,MX)
0R908 1-215-904-11 METAL OXIDE 100K 5% 2W
(EXCEPT US,CND,MX)
0R909 1-220-388-11 METAL OXIDE 68K 5% 1W
(US,CND,MX)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
POWER
Ver 1.2 2002.10
