Sony HCD-CP2 - Page 30

30
• Waveforms
– CD Board –
1 IC701 1 (FEO) (CD Play Mode)
2 IC701 ed (RF O), IC703 eg (RF)
(CD Play Mode)
3 IC701 rg (TEO) (CD Play Mode)
4 IC703 wa (MDP) (CD Play Mode)
6 IC703 rd (BCK) (CD Play Mode)
7 IC703 u; XTAI (CD Play Mode)
5 IC703 el (LRCK) (CD Play Mode)
2 IC802 ef (TX)
3 IC803 qd (XI)
Approx.
200 mVp-p
1.2 ± 0.1 Vp-p
Approx.
100 mVp-p
2.8 Vp-
p
7.6 µs
6.6 Vp-p
22.8 µs
6.4 Vp-p
472 ns
4.3 Vp-p
16.9344 MHz
– AUDIO Board –
1 Q621, 622 (Collector)
(Record Mode)
18.4 Vp-p
11.3 µs
– MAIN Board –
1 IC802 es (XTAL1)
5.2 Vp-p
4.19 MHz
5.2 Vp-p
32.768 kHz
2.9 Vp-p
4.332 MHz
4 IC803 qh (RCLK)
4.4 Vp-p
840 µs
