54
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
AUS : Australian model
AED : North European model
EA : Saudi Arabia model
SP : Singapore model
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-4426-642-A AMP BOARD, COMPLETE (AEP, UK, AED)
A-4426-842-A AMP BOARD, COMPLETE (EA, SP)
A-4473-065-A AMP BOARD, COMPLETE (AUS)
*********************
* 4-217-354-01 BUSHING, INSULATING
4-931-757-31 SCREW (DIA.2.6X8) (IT3B), TAPPING
< CAPACITOR >
C121 1-126-963-11 ELECT 4.7uF 20% 50V
C122 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C123 1-104-665-11 ELECT 100uF 20% 16V
C124 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C125 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C126 1-126-965-11 ELECT 22uF 20% 50V
C127 1-130-495-00 MYLAR 0.1uF 5% 50V
C132 1-104-665-11 ELECT 100uF 20% 16V
C133 1-130-495-00 MYLAR 0.1uF 5% 50V
C221 1-126-963-11 ELECT 4.7uF 20% 50V
C222 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C223 1-104-665-11 ELECT 100uF 20% 16V
C224 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C225 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C226 1-126-965-11 ELECT 22uF 20% 50V
C227 1-130-495-00 MYLAR 0.1uF 5% 50V
C232 1-104-665-11 ELECT 100uF 20% 16V
C233 1-130-495-00 MYLAR 0.1uF 5% 50V
C311 1-126-955-11 ELECT 4700uF 20% 35V
C340 1-126-955-11 ELECT 4700uF 20% 35V
C344 1-126-961-11 ELECT 2.2uF 20% 50V
C345 1-104-666-11 ELECT 220uF 20% 16V
C349 1-126-965-11 ELECT 22uF 20% 50V
C350 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
* CN310 1-568-936-11 PIN, CONNECTOR 9P
CN311 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D311 8-719-200-02 DIODE IN4002AT-93
< IC >
IC101 8-759-584-39 IC TDA7296
IC201 8-759-584-39 IC TDA7296
< SHORT >
JR101 1-216-295-00 SHORT 0
JR102 1-216-295-00 SHORT 0
< COIL >
L101 1-420-872-00 COIL, AIR-CORE
L201 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q120 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q220 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q331 8-729-230-91 TRANSISTOR 2SC2785-HFE
Q332 8-729-230-91 TRANSISTOR 2SC2785-HFE
Q333 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q335 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q336 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q337 8-729-027-46 TRANSISTOR DTC114YK-T146
< RESISTOR >
R121 1-216-190-00 RES, CHIP 470 5% 1/8W
R123 1-216-045-00 METAL CHIP 680 5% 1/10W
R124 1-216-081-00 METAL CHIP 22K 5% 1/10W
R125 1-216-091-00 METAL CHIP 56K 5% 1/10W
R126 1-216-097-00 RES, CHIP 100K 5% 1/10W
R127 1-216-150-91 RES, CHIP 10 5% 1/8W
R128 1-216-150-91 RES, CHIP 10 5% 1/8W
R221 1-216-190-00 RES, CHIP 470 5% 1/8W
R223 1-216-045-00 METAL CHIP 680 5% 1/10W
R224 1-216-081-00 METAL CHIP 22K 5% 1/10W
R225 1-216-091-00 METAL CHIP 56K 5% 1/10W
R226 1-216-097-00 RES, CHIP 100K 5% 1/10W
R227 1-216-150-91 RES, CHIP 10 5% 1/8W
R228 1-216-150-91 RES, CHIP 10 5% 1/8W
R328 1-216-097-00 RES, CHIP 100K 5% 1/10W
R329 1-216-093-11 RES, CHIP 68K 5% 1/10W
R330 1-216-089-00 RES, CHIP 47K 5% 1/10W
R331 1-216-121-00 RES, CHIP 1M 5% 1/10W
R332 1-216-073-00 METAL CHIP 10K 5% 1/10W
R333 1-216-049-11 RES, CHIP 1K 5% 1/10W
R334 1-216-097-00 RES, CHIP 100K 5% 1/10W
AMP
