29
7-11. PRINTED WIRING BOARDS – LCD/LOADING Boards –
• See page 23 for Circuit Boards Location.
M
M901
DISC TRAY
OPEN/CLOSE
S901
DISC TRAY
CLOSE DET
S902
DISC TRAY
OPEN DET
CN900
1
5
11
1-640-523-
F
LOADING BOARD
05
CN804
CN802
(Page 28)(Page 28)
(Page
28)
