Sony HCD-CP2 - Page 59

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
59
CONTROL HEADPHONE LCD LEAF SWITCH LOADING MAIN
S831 1-571-760-11 SWITCH, KEY BOARD (TAPE A Y)
S832 1-771-290-11 SWITCH, SLIDE (BASS)
S833 1-771-290-11 SWITCH, SLIDE (TREBLE)
**************************************************************
1-675-153-11 HEADPHONE BOARD
*****************
< JACK >
J301 1-785-925-11 JACK (PHONES)
**************************************************************
1-675-150-11 LCD BOARD
**********
4-217-319-01 PLATE, LCD LIGHT
< CONNECTOR >
CN802 1-793-599-11 SOCKET, CONNECTOR 17P
CN804 1-793-601-11 SOCKET, CONNECTOR 21P
< LED >
D657 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
D658 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
D659 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
D660 8-719-075-51 LED SELS6B14C-LF62 (LCD BACK LIGHT)
< SHORT >
JR601 1-216-296-00 SHORT 0
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-542-11 DISPLAY PANEL, LIQUID CRYSTAL
**************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
******************
< CONNECTOR >
* CN1001 1-695-372-31 PIN, CONNECTOR (PC BOARD) 11P
< PHOTO REFLECTOR >
Q1001 8-749-010-90 PHOTO REFLECTOR NJL5165KA-H2
Q1002 8-749-010-90 PHOTO REFLECTOR NJL5165KA-H2
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1KEY) (DECK A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1KEY) (DECK B PLAY)
S1003 1-572-248-11 SWITCH, LEAF (DECK A HALF)
S1004 1-571-281-21 SWITCH, LEAF (DECK A 120/70)
S1005 1-571-281-21 SWITCH, LEAF (DECK A REC)
S1006 1-572-248-11 SWITCH, LEAF (DECK B HALF)
S1008 1-571-281-21 SWITCH, LEAF (DECK B 120/70)
S1009 1-571-281-21 SWITCH, LEAF (DECK B REC)
**************************************************************
* 1-640-523-11 LOADING BOARD
**************
< CONNECTOR >
* CN900 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S901 1-692-667-11 SWITCH, LEAF (DISC TRAY CLOSE DET)
S902 1-692-667-11 SWITCH, LEAF (DISC TRAY OPEN DET)
**************************************************************
A-4426-641-A MAIN BOARD, COMPLETE (AEP, UK, AED)
A-4426-844-A MAIN BOARD, COMPLETE (EA, SP)
A-4428-617-A MAIN BAORD, COMPLETE (AUS)
*********************
A-4411-460-A TUNER PACK (AEP, UK, AED)
A-4426-617-A TUNER PACK (EA, SP, AUS)
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20% 50V
C102 1-126-963-11 ELECT 4.7uF 20% 50V
C103 1-126-963-11 ELECT 4.7uF 20% 50V
C104 1-126-963-11 ELECT 4.7uF 20% 50V
C105 1-126-963-11 ELECT 4.7uF 20% 50V
C106 1-126-963-11 ELECT 4.7uF 20% 50V
C107 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C109 1-126-963-11 ELECT 4.7uF 20% 50V
C110 1-126-963-11 ELECT 4.7uF 20% 50V
C111 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C112 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C113 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C114 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C115 1-163-014-00 CERAMIC CHIP 0.0027uF 10% 50V
C116 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C117 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C118 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C129 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C130 1-104-664-11 ELECT 47uF 20% 16V
C131 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C201 1-126-963-11 ELECT 4.7uF 20% 50V
C202 1-126-963-11 ELECT 4.7uF 20% 50V
C203 1-126-963-11 ELECT 4.7uF 20% 50V
C204 1-126-963-11 ELECT 4.7uF 20% 50V
C205 1-126-963-11 ELECT 4.7uF 20% 50V
C206 1-126-963-11 ELECT 4.7uF 20% 50V
C207 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C209 1-126-963-11 ELECT 4.7uF 20% 50V
C210 1-126-963-11 ELECT 4.7uF 20% 50V
C211 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C212 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C213 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C214 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C215 1-163-014-00 CERAMIC CHIP 0.0027uF 10% 50V
C216 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
