Sony HCD-CP2 - Page 61

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
61
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-982-11 DIODE MTZJ-T-77-4.3B (AEP, UK, AED)
D806 8-719-991-33 DIODE 1SS133T-77
D807 8-719-991-33 DIODE 1SS133T-77
D808 8-719-991-33 DIODE 1SS133T-77
D809 8-719-991-33 DIODE 1SS133T-77
D815 8-719-991-33 DIODE 1SS133T-77
D816 8-719-991-33 DIODE 1SS133T-77
< IC >
IC301 8-759-585-01 IC TDA7439
IC302 8-759-909-71 IC BA4558F-E2
IC304 8-759-584-41 IC K1A7808PI
IC305 8-759-584-40 IC KA7908
IC306 8-759-347-19 IC KIA7812PI
IC308 8-749-921-12 IC GP1F32T (OPTICAL DIGITAL OUT (CD))
IC309 8-759-584-65 IC KA3082
IC310 8-759-324-40 IC KIA7805PI
IC311 8-759-584-41 IC K1A7808PI
IC401 8-759-363-21 IC HA12203
IC402 8-759-584-65 IC KA3082
IC800 8-759-153-90 IC uPD7225GB-3B7
IC801 8-759-584-64 IC BMR0301H
IC802 8-752-908-92 IC CXP84332-168Q
IC803 8-759-557-36 IC BU1924F-E2 (AEP, UK, AED)
< SHORT>
JR301 1-216-296-00 SHORT 0
JR302 1-216-296-00 SHORT 0
JR303 1-216-296-00 SHORT 0
JR306 1-216-296-00 SHORT 0
JR307 1-216-296-00 SHORT 0
JR308 1-216-296-00 SHORT 0
JR309 1-216-296-00 SHORT 0
JR310 1-216-296-00 SHORT 0
JR312 1-216-296-00 SHORT 0
JR314 1-216-296-00 SHORT 0
JR315 1-216-296-00 SHORT 0
JR316 1-216-296-00 SHORT 0
JR317 1-216-296-00 SHORT 0
JR318 1-216-296-00 SHORT 0
JR322 1-216-296-00 SHORT 0
JR323 1-216-296-00 SHORT 0
JR324 1-216-296-00 SHORT 0
JR325 1-216-296-00 SHORT 0
JR326 1-216-296-00 SHORT 0
JR329 1-216-296-00 SHORT 0
JR330 1-216-296-00 SHORT 0
JR331 1-216-296-00 SHORT 0
JR332 1-216-296-00 SHORT 0
JR333 1-216-296-00 SHORT 0
JR334 1-216-296-00 SHORT 0
JR335 1-216-296-00 SHORT 0
JR338 1-216-296-00 SHORT 0
JR339 1-216-296-00 SHORT 0
JR340 1-216-296-00 SHORT 0
JR341 1-216-296-00 SHORT 0
JR342 1-216-296-00 SHORT 0
JR343 1-216-296-00 SHORT 0
JR344 1-216-296-00 SHORT 0
JR345 1-216-296-00 SHORT 0
JR351 1-216-295-00 SHORT 0
JR354 1-216-295-00 SHORT 0
JR355 1-216-295-00 SHORT 0
< JACK >
PJ303 1-785-926-11 JACK, PIN 6P (LINE OUT, MD IN, VIDEO IN)
< TRANSISTOR >
Q101 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q102 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q103 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q106 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q201 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q202 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q203 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q206 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q303 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q304 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q310 8-729-019-00 TRANSISTOR 2SD2394-G
Q311 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q312 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q313 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q314 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q315 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q316 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q317 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q318 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q321 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q322 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q323 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q324 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q403 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q406 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q407 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q408 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q409 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q800 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q801 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q804 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q805 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q806 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q830 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
(AEP, UK, AED)
Q850 8-729-801-84 TRANSISTOR 2SB1013-TP-34
Q851 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R103 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R105 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R106 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R107 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R108 1-216-072-00 METAL CHIP 9.1K 5% 1/10W
R109 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R110 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
MAIN
