Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
64
< VARIABLE RESISTOR >
RV301 1-225-213-21 RES, ADJ, CARBON 2.2K
RV351 1-225-213-21 RES, ADJ, CARBON 2.2K
< VIBRATOR >
X800 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X801 1-767-184-11 VIBRATOR, CERAMIC (4.19MHz)
X803 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz)
(AEP, UK, AED)
**************************************************************
1-675-155-11 POWER BOARD
*************
1-533-313-11 HOLDER, FUSE
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
(AEP, UK, AED, AUS)
C903 1-101-005-00 CERAMIC 22000PF 50V
(AEP, UK, AED, AUS)
C904 1-101-005-00 CERAMIC 22000PF 50V
(AEP, UK, AED, AUS)
C905 1-101-005-00 CERAMIC 22000PF 50V
(AEP, UK, AED, AUS)
C906 1-101-005-00 CERAMIC 22000PF 50V
(AEP, UK, AED, AUS)
C907 1-101-005-00 CERAMIC 22000PF 50V
C908 1-101-005-00 CERAMIC 22000PF 50V
C909 1-101-005-00 CERAMIC 22000PF 50V
C910 1-101-005-00 CERAMIC 22000PF 50V
C911 1-161-494-00 CERAMIC 0.022uF 25V
C912 1-161-494-00 CERAMIC 0.022uF 25V
C913 1-161-494-00 CERAMIC 0.022uF 25V
C914 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN901 1-766-276-11 PIN, CONNECTOR (PC BOARD) 3P
CN902 1-766-279-11 PIN, CONNECTOR (PC BOARD) 6P
CNP901 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D902 8-719-200-82 DIODE 11ES2-TA1B (AEP, UK, AED, AUS)
D903 8-719-200-82 DIODE 11ES2-TA1B (AEP, UK, AED, AUS)
D904 8-719-200-82 DIODE 11ES2-TA1B (AEP, UK, AED, AUS)
D905 8-719-200-82 DIODE 11ES2-TA1B (AEP, UK, AED, AUS)
D906 8-719-200-82 DIODE 11ES2-TA1B (AEP, UK, AED, AUS)
D907 8-719-902-17 DIODE 1N5401
D908 8-719-902-17 DIODE 1N5401
D909 8-719-902-17 DIODE 1N5401
D910 8-719-902-17 DIODE 1N5401
D911 8-719-046-07 DIODE 2A02M
D912 8-719-046-07 DIODE 2A02M
D913 8-719-046-07 DIODE 2A02M
D914 8-719-046-07 DIODE 2A02M
< FUSE >
0 F901 1-533-464-11 FUSE, TIME-LAG (DIA.5) (T0.8AL/250V)
0 F902 1-533-468-11 FUSE, TIME-LAG (DIA.5) (T2AL/250V)
0 F903 1-533-468-11 FUSE, TIME-LAG (DIA.5) (T2AL/250V)
< RELAY >
0 RY901 1-755-321-11 RELAY (AEP, UK, AED, AUS)
< SWITCH >
0 S901 1-552-921-00 SWITCH, POWER (VOLTAGE CHANGE)
(VOLTAGE SELECTOR) (EA, SP)
< TRANSFORMER >
0 T901 1-435-100-11 TRANSFORMER, POWER (AEP, UK, AED, AUS)
0 T901 1-435-101-11 TRANSFORMER, POWER (EA, SP)
0 T902 1-433-811-11 TRANSFORMER, POWER (AEP, UK, AED, AUS)
**************************************************************
MISCELLANEOUS
**************
57 1-791-437-11 WIRE (FLAT TYPE) (17 CORE)
58 1-791-438-11 WIRE (FLAT TYPE) (21 CORE) (180mm)
62 1-418-482-11 ILLUMINATION BLOCK, LED
66 1-791-435-11 WIRE (FLAT TYPE) (21 CORE) (105mm)
108 1-791-436-11 WIRE (FLAT TYPE) (21 CORE)
109 1-791-434-11 WIRE (FLAT TYPE) (11 CORE)
0 114 1-696-169-11 CORD, POWER
0 115 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
159 1-452-493-21 MAGNET
204 1-773-126-11 WIRE (FLAT TYPE) (19 CORE)
0 206 8-820-070-02 OPTICAL PICK-UP KSM-213CCP/K1N
209 1-773-113-11 WIRE, FLAT TYPE (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAY BACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M701 X-2646-381-1 MOTOR CHASSIS ASSY (MB) (SPINDLE)
M702 X-2625-769-1 MOTOR GEAR ASSY (MB) (RP) (SLED)
M901 X-2625-117-1 MOTOR ASSY, LOADING
0 T901 1-435-100-11 TRANSFORMER, POWER (AEP, UK, AED, AUS)
0 T901 1-435-101-11 TRANSFORMER, POWER (EA, SP)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
#2 7-685-245-14 SCREW +KTP 3X6 TYPE2 NON-SLIT
#3 7-685-647-79 SCREW +PTP DIA.12 WH 3
#4 7-685-659-14 SCREW +BVTP 4X8 TYPE2 N-S
#5 7-685-135-19 SCREW +P 2.6X10 TYPE2 NON-SLIT
#6 7-621-255-32 SCREW +P 2X5
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-623-921-01 RING, RETAINING, CAPSTAN
#12 7-621-775-00 SCREW +B 2.6X3
#13 7-621-775-10 SCREW +B 2.6X4
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN POWER
Sony Corporation
Audio Entertainment Group
9-928-969-12
2000E0030020-1F
Printed in Japan © 2000. 5
Published by HA Quality Assurance Dept.
HCD-CP2
