Sony HCD-CP2 - Page 7

7
TAPE MECHANISM DECK (TCM-220WR2E)
1 five screws
(BTP3 × 8)
2 screws (DIA. 12
)
3 harness
5 TCM-220WR2E
4 Push these buttons.
4 four screws
(BTP2.6 × 4)
1 connector
(CN651)
2 two rivets
3 Break the soldering of
two flexible flat cables.
5 AUDIO board
AUDIO BOARD
