Sony HCD-CPX11 - Close Lever; Dir Lever, Gear (IDL-B)

20
HCD-CPX11
3-15. CLOSE LEVER
3-16. DIR LEVER, GEAR (IDL-B)
1 washer (3-1-0.4)
2 close lever spring
4 shaft disc stop
5 close lever
3 claw
3 gear puley
2 claw
9 DIR lever
5 gear (IDL-A)
q; gear (IDL-B)
1 DIR spring
8 stopper
6 Loosen the screw.
7 Hold the Release lever
and change the direction.
4 gear (cap)
