SECTION 1
SERVICING NOTES
SERVICE POSITION OF THE TAPE MECHANISM DECK
tape mechanism deck
SERVICE POSITION OF THE S-MASTER AMP BOARD
S-MASTER AMP board
• Remove the switching regulator, the S-MASTER AMP board block first,
then remove the S-MASTER AMP board from the S-MASTER AMP board block.
