HCD-CPX11
6-4. PRINTED WIRING BOARD — TC SECTION —
• Semiconductor
Location
Ref. No. Location
D681 B-3
IC601 D-4
IC602 E-4
Q639 C-2
Q640 C-3
Q641 C-3
Q642 E-2
Q643 D-2
Q680 D-3
Q681 D-3
Q691 B-3
Q692 B-3
Q693 B-2
Q694 B-3
IC601
IC602
MAIN
BOARD
CN306
E
E
E
E
E
E
E
E
E
1
1
8
9
E
E
1
3
4
6
20
21
30
31
40 1
10
11
TAPE
MECHANISM
DECK
L-CH
R-CH
ERASE
1
2
3
4
5
6
HRPE901
(REC/PB/ERASE)
HEAD RELAY
BOARD
12
A
B
C
D
E
F
G
3456
• See page 27 for Circuit Boards Location. :Uses unleaded solder.
(Page 36)
