71
HCD-CPX11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R809 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R810 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R811 1-216-833-11 METAL CHIP 10K 5% 1/10W
R812 1-216-837-11 METAL CHIP 22K 5% 1/10W
R813 1-216-809-11 METAL CHIP 100 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R821 1-216-817-11 METAL CHIP 470 5% 1/10W
R822 1-216-817-11 METAL CHIP 470 5% 1/10W
R823 1-216-817-11 METAL CHIP 470 5% 1/10W
R825 1-216-805-11 METAL CHIP 47 5% 1/10W
R826 1-216-817-11 METAL CHIP 470 5% 1/10W
R828 1-216-817-11 METAL CHIP 470 5% 1/10W
< VARIABLE RESISTOR >
RV803 1-476-730-11 ENCODER, ROTARY (VOLUME)
RV805 1-418-859-21 ENCODER, ROTARY (BASS)
RV807 1-418-859-21 ENCODER, ROTARY (TREBLE)
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (?/1)
S802 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S803 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/DIRECTION/TUNING MODE)
S804 1-762-875-21 SWITCH, KEYBOARD (REPEAT/FM MODE)
S805 1-762-875-21 SWITCH, KEYBOARD (CD SYNCHRO)
S806 1-762-875-21 SWITCH, KEYBOARD (FUNCTON)
S807 1-771-574-21 SWITCH, TACTILE (TUNING + LM)
S808 1-771-574-21 SWITCH, TACTILE (
-
TUNING lm)
S809 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S810 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S811 1-762-875-21 SWITCH, KEYBOARD ((CD) Z)
S812 1-762-875-21 SWITCH, KEYBOARD (z REC)
S813 1-762-875-21 SWITCH, KEYBOARD ((TAPE) X)
S814 1-762-875-21 SWITCH, KEYBOARD ((TAPE) x)
S815 1-762-875-21 SWITCH, KEYBOARD (TAPE nN)
************************************************************
A-4750-356-A PRE AMP BOARD, COMPLETE
************************
< CAPACITOR >
C101 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-126-960-11 ELECT 1uF 20% 50V
C104 1-126-960-11 ELECT 1uF 20% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C107 1-126-960-11 ELECT 1uF 20% 50V
C108 1-130-476-00 MYLAR 0.0027uF 5% 50V
C109 1-130-496-00 MYLAR 0.12uF 5% 50V
C110 1-130-496-00 MYLAR 0.12uF 5% 50V
C111 1-126-964-11 ELECT 10uF 20% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C123 1-126-964-11 ELECT 10uF 20% 50V
C124 1-126-923-91 ELECT 220uF 20% 10V
C129 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C131 1-104-658-91 ELECT 100uF 20% 10V
C132 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-104-658-91 ELECT 100uF 20% 10V
C141 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C151 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C152 1-126-960-11 ELECT 1uF 20% 50V
C153 1-126-960-11 ELECT 1uF 20% 50V
C154 1-126-960-11 ELECT 1uF 20% 50V
C155 1-126-960-11 ELECT 1uF 20% 50V
C156 1-126-960-11 ELECT 1uF 20% 50V
C157 1-126-960-11 ELECT 1uF 20% 50V
C158 1-130-476-00 MYLAR 0.0027uF 5% 50V
C159 1-130-496-00 MYLAR 0.12uF 5% 50V
C160 1-130-496-00 MYLAR 0.12uF 5% 50V
C161 1-126-964-11 ELECT 10uF 20% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C173 1-126-964-11 ELECT 10uF 20% 50V
C174 1-126-923-91 ELECT 220uF 20% 10V
C179 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C180 1-126-923-91 ELECT 220uF 20% 10V
C181 1-104-658-91 ELECT 100uF 20% 10V
C182 1-126-960-11 ELECT 1uF 20% 50V
C183 1-104-658-91 ELECT 100uF 20% 10V
C185 1-126-960-11 ELECT 1uF 20% 50V
< CONNECTOR >
CN101 1-784-780-11 CONNECTOR, FFC 19P
CN102 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
< IC >
IC101 8-759-669-03 IC LC75342
IC102 8-759-656-83 IC NJM4580MD-(TE2)
< JACK >
J101 1-817-877-11 JACK, PIN 2P (MD (VIDEO))
< TRANSISTOR >
Q101 8-729-107-43 TRANSISTOR 2SC3624-L18
Q121 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q122 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q151 8-729-107-43 TRANSISTOR 2SC3624-L18
Q180 8-729-107-43 TRANSISTOR 2SC3624-L18
Q181 8-729-107-43 TRANSISTOR 2SC3624-L18
Q182 8-729-107-43 TRANSISTOR 2SC3624-L18
Q183 8-729-107-43 TRANSISTOR 2SC3624-L18
Q184 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q185 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R103 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R104 1-216-821-11 METAL CHIP 1K 5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
PRE AMPPANEL
