Sony HCD-GN1300D - DC Fan, Transformer, Main, and Front Board Disassembly

HCD-GN1300D
10
2-10. MAIN BOARD, FRONT BOARD SECTION
2-9. DC FAN, POWER TRANSFORMER (T1200)
3
TRANS board
2
CN1250 (13P)
6
CN1502 (3P)
4
power transformer (PT1201)
7
bracket (Fan)
1
four screws
(+BV SUMITITE S 4x8 ROUND)
5
two screws
(+BVTP 3 x 8)
9
Fan, DC
0
cushion, PT
8
two screws
(+BVTP 3 x 10)
8
MAIN board
q;
CN1302 (11P)
9
CN1303 (15P)
cover dust (top)
1
one screw
(+BVTP 3 x 8)
3
two screw
(+BVTP 3 x 8)
7
CN110 (11P)
CN133 (7 P)
5
CN111 (14P)
6
CN190 (15P)
4
four screws
(+BVTP 3 x 8)
cushion saranet
2
three screws
(+BVTP 3 x 8)
qa
qd
three screws
(+BVTP 3 x 8)
Front board section
Filter, clamp (ferrite core)
qf
qg
qs
qh
Ver. 1.3
