2-5. MIC BOARD, USB DVD BOARD, MIC VR BOARD, HEADPHONE BOARD
2-6. DISPLAY BOARD, STR BOARD, CD SW BOARD, METER DISPLAY ASSY
3
knob (MIC VR)
2
knob (MIC)
1
knob (MIC)
qs
two screws
(+BVTP 2.6 (3CR))
qf USB DVD board
ground plate (USB)
shield plate (MIC)
9
8
MIC DVD board
qd
two screws
(+BVTP 2.6 (3CR))
q;
one screw
(+BVTP 2.6 (3CR))
6
two screws
(+BVTP 2.6 (3CR))
4
two screws
(+BVTP 2.6 (3CR))
7
two screws
(+BVTP 2.6 (3CR))
5
DVD MIC VR board
qa HP board
qg
1
three screws
(+BVTP 2.6 (3CR))
3
four screws
(+BVTP 2.6 (3CR))
qa
six screws
(+BVTP 2.6 (3CR))
qf
two screws
(+BVTP 2.6 (3CR))
2
meter display assy
5
DISPLAY board
4
wire (flat type) (23 core)
(CN902)
qd
STR board
qg
CN901 (2P)
qs
CN903D (3P)
qh
CD SW board
6
knob (volume)
7
nut
8
holder (jog)
9
knob jog-p assy
q;
gear (encoder)
