Sony HCD-GN1300D - Front Panel and MIC;USB;DVD Board Disassembly

HCD-GN1300D
7
2-3. LOADING PANEL
2-4. FRONT PANEL SECTION
3
loading panel
2
Pull-out the disc tray.
1
Turn the gear to the direction of the arrow.
gear
chassis side
CD mechanism deck (CDM74KF)
By using (-) screw driver
7
wire (flat type) (11 core)
(CN102)
8
wire (flat type) (14 core)
(CN120)
6
wire (flat type) (23 core)
(CN101)
9
wire (flat type) (15 core)
(CN131)
CN1600 (5P)
0
front panel assy
3
3
2
four screws
(+BVTP 3 x 8)
1
one screw
(+BVTP 3 x 8)
one screw
(+BVTP 3 x 10)
3
one screw
(+BVTP 3 x 10)
4
CN124 (2P)
5
Ver. 1.3
