Sony HCD-GN1300D - Electrical Parts List - Miscellaneous and Notes

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
103103
214 1-500-657-11 CORD, FERRITE
215 1-400-092-11 CORD, FERRITE (EA)
216 1-481-528-11 FILTER, CLAMP (FERRITE CORE) (EA)
253 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
0
321 8-820-322-04 DEVICE, OPTICAL KHM-313CAB/C2NP
(including sled motor, spindle motor)
322 1-828-252-11 WIRE (FLAT TYPE) (24 CORE)
0 F1231 1-533-949-32 FUSE, CYLINDRICAL (TIME LAG)(T8AL/250V)
0 F1241 1-533-949-32 FUSE, CYLINDRICAL (TIME LAG) (T8AL/250V)
0 F1251 1-533-949-32 FUSE, CYLINDRICAL (TIME LAG) (T8AL/250V)
0 F1261 1-533-949-32 FUSE, CYLINDRICAL (TIME LAG) (T8AL/250V)
M741 A-1108-965-A MOTOR ASSY, TABLE (TABLE)
M751 A-1143-804-A MOTOR ASSY, LOADING
0 M891 1-787-344-11 FAN, DC
0 M892 1-787-344-11 FAN, DC
S711 1-477-680-12 ENCODER, ROTARY
S935 1-487-171-11 ROTARY ENCODER
0 PT1201 1-445-679-11 POWER TRANSFORMER (MAIN)
TU901 1-693-778-22 TUNER(FM/AM)
************************************************************
Ver. 1.3
Note: If wire (fl at type) is replaced, install it after bending
it in the same form as that before replacement.
