Sony HCD-GN1300D - Electrical Parts List - Diodes, ICs, Connectors, Jumper Resistors

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
9393
C636 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C637 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C638 1-126-964-11 ELECT 10uF 20% 50V
C639 1-126-964-11 ELECT 10uF 20% 50V
C640 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C641 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C642 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C643 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C644 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C645 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C646 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C647 1-126-923-91 ELECT 220uF 20% 10V
C648 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C649 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C650 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C651 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C654 1-126-934-11 ELECT 220uF 20% 16V
C700 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN001 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN101 1-784-784-11 CONNECTOR, FFC 23P
CN102 1-568-830-11 CONNECTOR, FFC 11P
CN103 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN110 1-573-843-11 CONNECTOR, BOARD TO BOARD 11P
CN111 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
* CN120 1-564-716-11 PIN, CONNECTOR (SMALL TYPE) 14P
CN124 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
* CN125 1-564-506-11 PLUG, CONNECTOR 3P
CN130 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN131 1-779-283-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN132 1-784-774-11 CONNECTOR, FFC 13P
CN133 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
* CN150 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN151 1-568-826-11 CONNECTOR, FFC 7P
CN160 1-784-770-11 CONNECTOR, FFC 9P
CN190 1-573-847-11 CONNECTOR, BOARD TO BOARD
< DIODE >
D001 6-501-738-01 DIODE MAZ8062GMLS0
D002 6-501-743-01 DIODE MAZ8068GMLS0
D003 6-502-994-01 DIODE D10XB60 F
D006 6-502-272-01 DI RB055L-40TE25
D008 6-502-272-01 DI RB055L-40TE25
D009 6-502-272-01 DI RB055L-40TE25
D012 6-501-734-01 DIODE MAZ8056GMLS0
D104 6-501-817-01 DIODE MA2J1110GLS0
D119 6-501-743-01 DIODE MAZ8068GMLS0
D125 6-501-764-01 DIODE MAZ8110GMLS0
D468 6-501-817-01 DIODE MA2J1110GLS0
D469 6-501-817-01 DIODE MA2J1110GLS0
D470 6-501-817-01 DIODE MA2J1110GLS0
D499 6-501-817-01 DIODE MA2J1110GLS0
D500 6-501-817-01 DIODE MA2J1110GLS0
D501 6-501-734-01 DIODE MAZ8056GMLS0
D502 6-501-817-01 DIODE MA2J1110GLS0
D503 6-500-334-01 DIODE MC2836-T112-1
D504 6-501-722-01 DIODE MAZ8043GMLS0
D505 6-501-817-01 DIODE MA2J1110GLS0
D569 6-500-848-01 DIODE MC2840-T112-1
D570 6-500-848-01 DIODE MC2840-T112-1
D600 6-500-335-01 DIODE MC2838-T112-1
D601 6-501-722-01 DIODE MAZ8043GMLS0
D633 6-501-817-01 DIODE MA2J1110GLS0
D634 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC001 6-713-031-01 IC KIA7805API-U/PF
IC002 6-714-167-01 IC BD9702CP-V5
IC003 6-701-760-01 IC uPC3504AHF
IC004 6-714-166-01 IC BD9701CP-V5
IC005 8-759-394-36 IC BA09T
IC006 6-714-166-01 IC BD9701CP-V5
IC100 A-1736-332-A IC R5F3640MDFAR (UCOM SERVICE)
IC101 6-712-027-01 IC R2A15216FP
IC102 6-703-651-11 IC M61530FP-D60G
IC252 8-759-278-58 IC NJM4558V-TE2
IC253 8-759-278-58 IC NJM4558V-TE2
IC256 8-759-700-07 IC NJM2903M
IC600 8-759-278-58 IC NJM4558V-TE2
IC601 8-759-278-58 IC NJM4558V-TE2
IC675 6-713-627-01 IC BR24S16FJ -WE2
< JACK >
J200 1-794-981-11 JACK, PIN 4P (TV/SAT AUDIO IN, AUDIO OUT)
< JUMPER RESISTOR >
JR001 1-216-295-91 SHORT CHIP 0
JR002 1-216-296-11 SHORT CHIP 0
JR003 1-216-295-91 SHORT CHIP 0
JR004 1-216-295-91 SHORT CHIP 0
JR005 1-216-295-91 SHORT CHIP 0
JR006 1-216-295-91 SHORT CHIP 0
JR007 1-216-296-11 SHORT CHIP 0
JR008 1-216-296-11 SHORT CHIP 0
JR009 1-216-295-91 SHORT CHIP 0
JR010 1-216-295-91 SHORT CHIP 0
JR012 1-216-295-91 SHORT CHIP 0
JR013 1-216-295-91 SHORT CHIP 0
JR014 1-216-295-91 SHORT CHIP 0
JR015 1-216-295-91 SHORT CHIP 0
JR400 1-216-864-11 SHORT CHIP 0
JR401 1-216-864-11 SHORT CHIP 0
JR402 1-216-296-11 SHORT CHIP 0
JR403 1-216-296-11 SHORT CHIP 0
JR404 1-216-864-11 SHORT CHIP 0
JR405 1-216-296-11 SHORT CHIP 0
JR406 1-216-864-11 SHORT CHIP 0
JR407 1-216-296-11 SHORT CHIP 0
JR408 1-216-296-11 SHORT CHIP 0
JR409 1-216-864-11 SHORT CHIP 0
JR410 1-216-864-11 SHORT CHIP 0
JR411 1-216-296-11 SHORT CHIP 0
JR412 1-216-864-11 SHORT CHIP 0
JR413 1-216-864-11 SHORT CHIP 0
JR414 1-216-864-11 SHORT CHIP 0
JR415 1-216-864-11 SHORT CHIP 0
JR416 1-216-296-11 SHORT CHIP 0
JR417 1-216-296-11 SHORT CHIP 0
JR419 1-216-864-11 SHORT CHIP 0
MAIN
Ver. 1.3
