64
HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
GAME
DRIVER
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-338-11 PIN, CONNECTOR (LIGHT ANGLE) 12P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-247-831-91 CARBON 1K 5% 1/4W
R712 1-247-847-91 CARBON 4.7K 5% 1/4W
R713 1-247-863-91 CARBON 22K 5% 1/4W
R721 1-247-847-91 CARBON 4.7K 5% 1/4W
R722 1-247-847-91 CARBON 4.7K 5% 1/4W
R723 1-247-847-91 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-247-831-91 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-847-91 CARBON 4.7K 5% 1/4W
************************************************************
A-4750-976-A GAME BOARD, COMPLETE (GN660/GN770)
A-4751-304-A GAME BOARD, COMPLETE (GX9000)
*******************
< CAPACITOR >
C801 1-126-923-91 ELECT 220uF 20% 10V
C802 1-126-957-11 ELECT 0.22uF 20% 50V
C803 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C804 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C805 1-126-964-11 ELECT 10uF 20% 50V
C806 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C807 1-126-961-11 ELECT 2.2uF 20% 50V
C809 1-124-250-11 ELECT 0.15uF 20% 50V
C810 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C811 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C812 1-126-964-11 ELECT 10uF 20% 50V
C813 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C814 1-124-261-00 ELECT 10uF 20% 50V
C816 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C817 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C838 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C839 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C840 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C841 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C845 1-126-964-11 ELECT 10uF 20% 50V
C846 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
CN802 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
EPT802 1-537-738-21 TERMINAL, GROUND
EPT803 1-537-738-21 TERMINAL, GROUND
EPT804 1-537-738-21 TERMINAL, GROUND
< IC >
IC850 8-759-710-97 IC NJM4565M-D
< JACK >
J801 1-817-629-11 JACK (LARGE TYPE) (MIC)
J850 1-764-592-11 JACK 3P (GAME INPUT)
J851 1-794-702-11 JACK, HEADPHONE (PHONES)
< SHORT >
JR810 1-216-864-11 SHORT CHIP 0
JR811 1-216-864-11 SHORT CHIP 0
JR812 1-216-864-11 SHORT CHIP 0
JR813 1-216-864-11 SHORT CHIP 0
JR815 1-216-864-11 SHORT CHIP 0
JR816 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R801 1-216-845-11 METAL CHIP 100K 5% 1/10W
R802 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R803 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R804 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-216-848-11 METAL CHIP 180K 5% 1/10W
R806 1-216-833-11 METAL CHIP 10K 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-837-11 METAL CHIP 22K 5% 1/10W
R809 1-216-821-11 METAL CHIP 1K 5% 1/10W
R810 1-216-845-11 METAL CHIP 100K 5% 1/10W
R811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R813 1-216-821-11 METAL CHIP 1K 5% 1/10W
R814 1-216-833-11 METAL CHIP 10K 5% 1/10W
R827 1-216-845-11 METAL CHIP 100K 5% 1/10W
R828 1-216-845-11 METAL CHIP 100K 5% 1/10W
R829 1-216-821-11 METAL CHIP 1K 5% 1/10W
R830 1-216-821-11 METAL CHIP 1K 5% 1/10W
