65
HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description RemarksRef. No. Part No. Description Remarks
MAIN
JOG
< VARIABLE RESISTOR >
RV801 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL)
************************************************************
JOG BOARD
*********
< CAPACITOR >
C964 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C965 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< SWITCH >
S957 1-478-662-11 ENCODER, ROTARY (MULTI JOG)
************************************************************
A-4750-981-A MAIN PC BOARD ASSY (GN660: E2)
A-4750-989-A MAIN PC BOARD ASSY (GN770: E2)
A-4750-999-A MAIN PC BOARD ASSY (GX9000)
A-4753-110-A MAIN PC BOARD ASSY (GN660: E3)
A-4753-116-A MAIN PC BOARD ASSY (GN660: E51)
A-4753-120-A MAIN PC BOARD ASSY (GN660: MX)
A-4753-123-A MAIN PC BOARD ASSY (GN660:AR)
A-4753-126-A MAIN PC BOARD ASSY (GN770: E3)
A-4753-129-A MAIN PC BOARD ASSY (GN770:AUS)
A-4753-133-A MAIN PC BOARD ASSY (GN770: E51)
A-4753-139-A MAIN PC BOARD ASSY (GN770: MX)
****************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C101 1-124-261-00 ELECT 10uF 20% 50V
C103 1-124-261-00 ELECT 10uF 20% 50V
C104 1-124-261-00 ELECT 10uF 20% 50V
C105 1-126-964-11 ELECT 10uF 20% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-136-497-81 FILM 0.1uF 5% 50V
C108 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C109 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C110 1-126-964-11 ELECT 10uF 20% 50V
C111 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C112 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C113 1-126-964-11 ELECT 10uF 20% 50V
C114 1-136-170-00 FILM 0.27uF 5% 50V
C115 1-137-195-11 FILM 0.56uF 5% 50V
C116 1-126-963-11 ELECT 4.7uF 20% 50V
C119 1-126-157-11 ELECT 10uF 20% 16V
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C121 1-126-160-11 ELECT 1uF 20% 50V
C122 1-124-261-00 ELECT 10uF 20% 50V
C123 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C124 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C125 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C126 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C127 1-126-947-11 ELECT 47uF 20% 35V
C128 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C129 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C130 1-104-658-91 ELECT 100uF 20% 10V
C131 1-126-959-11 ELECT 0.47uF 20% 50V
C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C134 1-124-261-00 ELECT 10uF 20% 50V
C135 1-126-933-11 ELECT 100uF 20% 16V
C136 1-126-933-11 ELECT 100uF 20% 16V
C137 1-126-935-11 ELECT 470uF 20% 16V
C138 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C139 1-137-150-11 FILM 0.01uF 5% 100V
C140 1-126-947-11 ELECT 47uF 20% 35V
C141 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C142 1-130-481-00 MYLAR 0.0068uF 5% 50V
C143 1-128-131-11 ELECT 22uF 20% 50V
C144 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C145 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C146 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C147 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C148 1-124-257-00 ELECT 2.2uF 20% 50V
C150 1-126-964-11 ELECT 10uF 20% 50V
C151 1-126-964-11 ELECT 10uF 20% 50V
C153 1-126-964-11 ELECT 10uF 20% 50V
C154 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-126-964-11 ELECT 10uF 20% 50V
C157 1-136-497-81 FILM 0.1uF 5% 50V
C158 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C159 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C160 1-126-964-11 ELECT 10uF 20% 50V
C161 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C162 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C163 1-126-964-11 ELECT 10uF 20% 50V
C164 1-136-170-00 FILM 0.27uF 5% 50V
C165 1-137-195-11 FILM 0.56uF 5% 50V
C166 1-126-963-11 ELECT 4.7uF 20% 50V
C169 1-126-157-11 ELECT 10uF 20% 16V
C170 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C171 1-126-960-11 ELECT 1uF 20% 50V
C172 1-126-964-11 ELECT 10uF 20% 50V
C173 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C174 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C175 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C176 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C177 1-137-194-81 FILM 0.47uF 5% 50V
C178 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C179 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C186 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C187 1-104-658-91 ELECT 100uF 20% 10V
C188 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C189 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C190 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C192 1-126-960-11 ELECT 1uF 20% 50V
C194 1-126-964-11 ELECT 10uF 20% 50V
C195 1-126-160-11 ELECT 1uF 20% 50V
C196 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C197 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C198 1-126-961-11 ELECT 2.2uF 20% 50V
C199 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C200 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C301 1-126-964-11 ELECT 10uF 20% 50V
C302 1-136-497-81 FILM 0.1uF 5% 50V
