74
HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
PANEL PRIMARY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
R949 1-216-821-11 METAL CHIP 1K 5% 1/10W
R950 1-216-821-11 METAL CHIP 1K 5% 1/10W
R951 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R952 1-216-821-11 METAL CHIP 1K 5% 1/10W
R953 1-216-821-11 METAL CHIP 1K 5% 1/10W
R954 1-216-833-11 METAL CHIP 10K 5% 1/10W
R956 1-216-833-11 METAL CHIP 10K 5% 1/10W
R957 1-216-845-11 METAL CHIP 100K 5% 1/10W
R958 1-216-817-11 METAL CHIP 470 5% 1/10W
R959 1-216-819-11 METAL CHIP 680 5% 1/10W
R960 1-216-821-11 METAL CHIP 1K 5% 1/10W
R961 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R962 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R963 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R964 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R965 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R966 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R975 1-216-817-11 METAL CHIP 470 5% 1/10W
R977 1-216-821-11 METAL CHIP 1K 5% 1/10W
R978 1-216-817-11 METAL CHIP 470 5% 1/10W
R980 1-216-821-11 METAL CHIP 1K 5% 1/10W
R981 1-216-821-11 METAL CHIP 1K 5% 1/10W
R982 1-216-821-11 METAL CHIP 1K 5% 1/10W
R983 1-216-821-11 METAL CHIP 1K 5% 1/10W
R987 1-216-821-11 METAL CHIP 1K 5% 1/10W
R988 1-216-821-11 METAL CHIP 1K 5% 1/10W
R989 1-216-821-11 METAL CHIP 1K 5% 1/10W
R993 1-216-821-11 METAL CHIP 1K 5% 1/10W
R994 1-216-821-11 METAL CHIP 1K 5% 1/10W
R995 1-216-821-11 METAL CHIP 1K 5% 1/10W
R999 1-216-864-11 SHORT CHIP 0
R1303 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1304 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1305 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1306 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1307 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1308 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1312 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1313 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1314 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1318 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1319 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1320 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1324 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1325 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1326 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1330 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1331 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1332 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S900 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S901 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE, TUNING MODE)
S902 1-762-875-21 SWITCH, KEYBOARD (REPEAT, FM MODE)
S903 1-762-875-21 SWITCH, KEYBOARD
(DIRECTION, TUNER MEMORY)
S904 1-762-875-21 SWITCH, KEYBOARD (n N)
S905 1-762-875-21 SWITCH, KEYBOARD (SURR SPEAKER MODE)
S906 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
S907 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S908 1-762-875-21 SWITCH, KEYBOARD (ILLUMINATION)
S909 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S910 1-762-875-21 SWITCH, KEYBOARD (EQ EDIT)
S911 1-762-875-21 SWITCH, KEYBOARD (P FILE MEMORY)
S912 1-762-875-21 SWITCH, KEYBOARD (X)
S913 1-762-875-21 SWITCH, KEYBOARD (x)
S914 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S915 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S924 1-762-875-21 SWITCH, KEYBOARD (SLEEP)
S925 1-762-875-21 SWITCH, KEYBOARD (AMP MENU)
S927 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING)
S928 1-762-875-21 SWITCH, KEYBOARD (GAME)
S929 1-762-875-21 SWITCH, KEYBOARD (VIDEO/MD)
S930 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S931 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S932 1-762-875-21 SWITCH, KEYBOARD (CD)
S970 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
< VIBRATOR >
X901 1-781-282-51 VIBRATOR, CERAMIC (4MHz)
************************************************************
A-4750-964-A PRIMARY BOARD, COMPLETE (E2, E3, E51)
A-4750-997-A PRIMARY BOARD, COMPLETE (GX9000)
A-4753-137-A PRIMARY BOARD, COMPLETE (MX)
A-4753-146-A PRIMARY BOARD, COMPLETE (AR, AUS)
**********************
< CAPACITOR >
0C1000 1-113-925-11 CERAMIC 0.01uF 20% 250V
C1001 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1002 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1003 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1005 1-126-916-11 ELECT 1000uF 20% 6.3V
< CONNECTOR >
CN1000 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN1001 1-566-664-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(EXCEPT MX, US)
* CN1001 1-568-226-11
PIN, CONNECTOR (3.96mm PITCH) 2P (MX, US)
CN1002 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D1000 8-719-988-61 DIODE 1SS355TE-17
< COIL >
L1001 1-410-666-31 INDUCTOR 18uH
< TRANSISTOR >
Q1000 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
< RESISTOR >
R1000 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1001 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1003 1-216-864-11 SHORT CHIP 0
