75
HCD-GN660/GN770/GX9000
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SENSOR SURROUND
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
0R1004 1-219-237-11 SOLID 3.3M 20% 1/2W
(GX9000)
< RELAY >
0RY1000 1-755-299-11 RELAY
< SWITCH >
0S1000 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR)
(E2, E3, E51)
************************************************************
1-687-132-12 SENSOR BOARD
************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 6-600-022-01 IC RPI-576
************************************************************
A-1053-545-A SURROUND BOARD, COMPLETE
(MX, AR, AUS, US)
A-4750-965-A SURROUND BOARD, COMPLETE (E2, E3, E51)
************************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C760 1-130-483-00 MYLAR 0.01uF 5% 50V
C761 1-130-483-00 MYLAR 0.01uF 5% 50V
< CONNECTOR >
CN701 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
* CN703 1-564-508-11 PLUG, CONNECTOR 5P (E2, E3, E51)
< DIODE >
D701 8-719-988-61 DIODE 1SS355TE-17 (E2, E3, E51)
D702 8-719-988-61 DIODE 1SS355TE-17
D763 8-719-500-56 DIODE D3SBA20
< TRANSISTOR >
Q701 8-729-014-97 TRANSISTOR FA1L3Z-T1B (E2, E3, E51)
< RESISTOR >
R707 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(E2, E3, E51)
R708 1-216-842-11 METAL CHIP 56K 5% 1/10W
(E2, E3, E51)
R709 1-216-833-11 METAL CHIP 10K 5% 1/10W
******************************************************
1-687-669-12 SW BOARD
********
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (LEVER SW)
******************************************************
SWITCH BOARD
************
< CONNECTOR >
CN903 1-779-978-11 PIN, CONNECTOR 3P
< RESISTOR >
R847 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R848 1-216-833-11 METAL CHIP 10K 5% 1/10W
R849 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S916 1-478-547-11 ENCODER, ROTARY (. >)
S917 1-771-963-11 SWITCH, ROTARY (m M ALBUM)
******************************************************
MISCELLANEOUS
*************
0 1-569-008-21 ADAPTOR, CONVERSION 2P (E51)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
6 1-500-497-11 FILTER, CLAMP (FERRITE CORE)
7 1-693-603-11 TUNER (FM/AM) (GN660/GN770)
7 1-693-623-11 TUNER (FM/AM) (GX9000)
08 1-468-737-21 POWER, SWITCHING
65 1-773-109-11 WIRE (FLAT TYPE) (19 CORE) (GN660)
65 1-773-109-11 WIRE (FLAT TYPE) (19 CORE) (GN770/GX9000)
71 1-796-486-61 DECK, MECHANICAL (GN660/GX9000)
71 1-796-487-51 DECK, MECHANICAL (GN770)
0104 1-696-847-22 CORD, POWER (AUS)
0104 1-777-071-53 CORD, POWER (E51)
0104 1-783-820-11 CORD, POWER (GX9000)
0104 1-783-941-12 CORD, POWER (AR)
0104 1-827-226-11 CORD, POWER (E2, E3, MX)
152 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
226 1-827-992-11 WIRE (FLAT TYPE) (16 CORE)
227 1-775-248-11 WIRE (FLAT TYPE) (27 CORE) (GN660/GN770)
227 1-775-248-11 WIRE (FLAT TYPE) (27 CORE) (GX9000)
0229 8-820-244-01 OPTICAL PICK-UP (KSM-215DCP/C2NP)
230 1-471-035-11 MAGNET ASSY
0F696 1-576-537-12 FUSE, GLASS TUBE (DIA.5) (8A/125V)(GX9000)
0F696 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (T8.0AL/250V)
(GN660/GN770)
0F697 1-576-537-12 FUSE, GLASS TUBE (DIA.5) (8A/125V)(GX9000)
0F697 1-576-655-12 FUSE, GLASS TUBE (DIA. 5) (T8.0AL/250V)
(GN660/GN770)
0F698 1-533-454-12 FUSE, GLASS TUBE (DIA. 5) (6.3A/125V)
(GX9000)
0F698 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
(GN660/GN770)
0F699 1-533-454-12 FUSE, GLASS TUBE (DIA. 5) (6.3A/125V)
(GX9000)
0F699 1-533-473-12 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
(GN660/GN770)
0F760 1-533-451-12 FUSE, GLASS TUBE (DIA. 5) (3.15A/125V)
(GX9000)
0F760 1-533-470-12 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
(GN660/GN770)
FL901 1-518-981-11 VACUUM FLUORESCENT DISPLAYS
