Sony HCD-GNV99D - Front Panel Assembly

10
HCD-GNV99D/GNV111D
lug
1 two screws
(+BVTP 3
´ 10)
2 two screws
(+BVTP 3
´ 10)
4 screw
(+BVTP 3
´ 10)
5 screw
(+BVTP 3
´ 6)
6 front panel assy
3 screw
(+BVTP 3
´ 10)
7 connector
(CN1102)
8 connector
(CN504)
9 connector
(CN503)
qs connector
(CN100)
0 flat wire
(CN508)
qa flat wire
(CN509)
qd connector
(CN802)
3-4. FRONT PANEL ASSY
