HCD-GNV99D/GNV111D
2
Remove the two solderings of motor.
4
MOTOR (LD) board
1
b
elt (loading)
5
l
oading motor assy (M751)
3
two
screws
(+BTTP (M2.6))
3-20. MOTOR (LD) BOARD
