HCD-GNV99D/GNV111D
1
connector
(CN1213)
2
connector
(CN1212)
3
screw
(+BVTP 3
´
6)
4
two screws
(+BVTP 3
´
6)
5
screw
(+BVTP 3
´
6)
6
screw
(+BVTP 3
´
10)
7
power AMP PC board assy
8
two screws
(+BVTP 3
´
10)
9
screw
(+BVTP 3
´
10)
q;
MAIN board
1
two screw
s
(transistor)
2
screw
(+BVTP 3
´
10)
3
DVD SURR board
4
connector
(CN602)
5
two screws
(+BVTP 3
´
10)
6
holder
7
three screws
(+BVTP 3
´
10)
8
two screws
(transistor)
9
two screws
(+BVTP 3
´
10)
0
heat sink
qa
screw
(+BVTP 3
´
10)
qs
bracket
qd
PA board
3-12. POWER AMP PC BOARD ASSY, MAIN BOARD
3-13. DVD SURR BOARD, PA BOARD
