78
HCD-GNV99D/GNV111D
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
AUS: Australian model
E2 : 120V AC Area in E model
E3 : 240V AC Area in E model
E12 : 220V-240V AC Area in E model
E13 : 220V-230V AC Area in E model
E15 : Iran model
EA : Saudi Arabia model
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board.
CD-SW BOARD
************
< CAPACITOR >
C1146 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(GNV111D)
< RESISTOR >
R1149 1-216-837-11 METAL CHIP 22K 5% 1/10W
(GNV111D)
R1150 1-216-835-11 METAL CHIP 15K 5% 1/10W
(GNV111D)
R1151 1-216-833-11 METAL CHIP 10K 5% 1/10W
(GNV111D)
R1152 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(GNV111D)
R1153 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(GNV111D)
R1154 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(GNV111D)
R1155 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(GNV111D)
R1169 1-216-817-11 METAL CHIP 470 5% 1/10W
R1170 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(GNV111D)
R1171 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1172 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1173 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1174 1-216-819-11 METAL CHIP 680 5% 1/10W
R1193 1-216-821-11 METAL CHIP 1K 5% 1/10W
(GNV111D)
< SWITCH >
S1148 1-478-133-11 ENCODER, ROTARY (X-ROUND JOG)(GNV111D)
S1149 1-762-875-21 SWITCH, KEYBOARD (TWISTER) (GNV111D)
S1150 1-762-875-21 SWITCH, KEYBOARD (RANDOM) (GNV111D)
S1151 1-762-875-21 SWITCH, KEYBOARD (AUTO/MANUAL)
(GNV111D)
S1152 1-762-875-21 SWITCH, KEYBOARD (BALANCE) (GNV111D)
S1153 1-762-875-21 SWITCH, KEYBOARD (FADER) (GNV111D)
S1154 1-762-875-21 SWITCH, KEYBOARD (WAVE) (GNV111D)
S1155 1-762-875-21 SWITCH, KEYBOARD
(SPEAKERS/X-ROUND OFF) (GNV111D)
S1156 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S1157 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S1158 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S1159 1-762-875-21 SWITCH, KEYBOARD (EX-CHANGE/DISC SKIP)
S1160 1-762-875-21 SWITCH, KEYBOARD (Z OPEN/CLOSE)
*************************************************************
A-1099-272-A DMB10 BOARD, COMPLETE (E3, E12, E13, E15)
A-1099-344-A DMB10 BOARD, COMPLETE (E2, MX)
A-1115-290-A DMB10 BOARD, COMPLETE (TH)
A-1115-347-A DMB10 BOARD, COMPLETE (MY, SP, PH)
A-1124-409-A DMB10 BOARD, COMPLETE (EA, AUS)
**********************
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C105 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C112 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-124-779-00 ELECT CHIP 10uF 20% 16V
C118 1-124-779-00 ELECT CHIP 10uF 20% 16V
C119 1-124-779-00 ELECT CHIP 10uF 20% 16V
C120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C121 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C122 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C123 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C124 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C128 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C129 1-124-779-00 ELECT CHIP 10uF 20% 16V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
CD-SW DMB10
MY : Malaysia model
MX : Mexican model
PH : Philippines model
SP : Singapore model
TH : Thai model
Ver. 1.1
