Sony HCD-GNV99D - Case; Loading Panel Assy

9
HCD-GNV99D/GNV111D
1 two screws
(case 3 TP2)
(3
´ 8)
2 screw
(case 3 TP2)
(3
´ 12)
3 two screws
(case 3 TP2)
(3
´ 8)
4 screw
(case 3 TP2)
(3
´ 12)
5 three screws
(+BVTP 3
´ 10)
6 four screws
(+BVTP 3
´ 10
)
6
7
CASE
3-2. CASE
DVD mechanismdeck (CDM74H-DVBU101)
1 Tu rn the pulley to the arrow direction.
Front side
Pulley
2 Pull out disc tray
3
4
loading panel assy
3-3. LOADING PANEL ASSY
