Sony HCD-GNV99D - Sensor Board; Motor (TB) Board

20
HCD-GNV99D/GNV111D
2 t ray
3 b elt (table)
5 p ulley (table)
8 s crew
(+BTTP (M2.6))
0 SENSOR board
7 g ear (geneva)
9 connector
( CN731)
1 floating screw
(+PTPWH M2.6)
6 floating screw
(+PTPWH M2.6)
4 floating screw
(+PTPWH M2.6)
6 Remove the two solderings of motor.
8 MOTOR (TB) board
7 t able motor assy (M741)
5 two screws
(+BTTP (M2.6))
4
3
flat wire 5p (CN742)
1 stopper
2 stopper
table
3-18. SENSOR BOARD
3-19. MOTOR (TB) BOARD
