Sony HCD-GNV99D - Page 5

5
HCD-GNV99D/GNV111D
J-2501-102-A
(1mm/13p/L300)
J-2501-086-A
(1mm/19p/L300)
DMB10 board
MAIN boar
d
DVD mechanism deck
CN521
CN520
CN106
CN302
front panel assy
TCM block
CN509
CN508
back panel
PA board
PANEL board
MAIN board
DVD SURR board
J-2501-167-A
(1.25mm/17p/L300)
J-2501-077-A
(1.25mm/13p/L300)
• Service Position-1 (DMB10 Board)
• Service Position-2 (PA and DVD SURR Boards)
