80
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNV99D/GNV111D
C3743 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3744 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3751 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3752 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3753 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3754 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3761 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3762 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3763 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3764 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3771 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3772 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3773 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3774 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3781 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3782 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3783 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3784 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C3801 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3802 1-117-370-11 CERAMIC CHIP 10uF 10V
C3803 1-124-779-00 ELECT CHIP 10uF 20% 16V(TH)
C3803 1-126-209-11 ELECT CHIP 100uF 20% 4V
(EXCEPT TH)
C3804 1-124-779-00 ELECT CHIP 10uF 20% 16V(TH)
C3804 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
(EXCEPT TH)
C3805 1-126-208-21 ELECT CHIP 47uF 20% 4V
(EXCEPT TH)
< CONNECTOR >
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN103 1-784-365-21 CONNECTOR, FFC/FPC 5P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN106 1-793-989-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 13P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN301 1-793-989-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 13P
CN302 1-778-691-11 CONNECTOR, FFC/FPC 19P
CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P
< DIODE >
D1001 8-719-058-24 DIODE RB501V-40TE-17
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
D3601 8-719-988-61 DIODE 1SS355TE-17
D3602 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL101 1-234-177-21 FILTER, CHIP EMI
FL104 1-234-177-21 FILTER, CHIP EMI
FL105 1-234-177-21 FILTER, CHIP EMI
FL106 1-234-177-21 FILTER, CHIP EMI
FL107 1-234-177-21 FILTER, CHIP EMI
FL108 1-234-177-21 FILTER, CHIP EMI
FL401 1-234-177-21 FILTER, CHIP EMI
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-177-21 FILTER, CHIP EMI
< IC >
IC101 6-805-261-01 IC MBM29DL32TF70-CBA2-0501UC (E2, MX)
IC101 6-805-262-01 IC MBM29DL32TF70-CBA2-0501CE
(E3, E12, E13, E15, EA, AUS)
IC101 6-805-263-01 IC MBM29DL32TF70-CBA2-0501GA
(MY, SP, TH, PH)
IC102 6-706-727-01 IC CXD9804R
IC103 (Not Supplied) IC BR24L64F-WE2
IC104 6-705-929-01 IC K4S641632H-UC75T
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 6-708-153-01 IC PQ018EN01ZPH
IC107 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC301 6-704-222-01 IC AK4358VQ-L
IC3601 6-707-608-01 IC PCM1803DBR
IC3711 8-759-359-49 IC NJM3414AV (TE2)
IC3731 8-759-359-49 IC NJM3414AV (TE2)
IC3751 8-759-359-49 IC NJM3414AV (TE2)
IC3771 8-759-359-49 IC NJM3414AV (TE2)
< COIL >
L3601 1-469-555-21 INDUCTOR 10uH
L3602 1-469-555-21 INDUCTOR 10uH
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q3801 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
DMB10
New part of EEPROM (IC103) on the DMB10 board can not be used. Therefore, if the mounted DMB10
board (A-1099-272-A or A-1099-344-A or A-1115-347-A) is replaced, exchange new EEPROM with
that used before the replacement.
Ver. 1.1
