83
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNV99D/GNV111D
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 20% 16V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-735-11 CONNECTOR, FFC 13P (TH)
CN701 1-785-338-11 PIN, CONNECTOR (LIGHT ANGLE) 12P
(EXCEPT TH)
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-247-831-91 CARBON 1K 5% 1/4W
R712 1-247-847-91 CARBON 4.7K 5% 1/4W
R713 1-247-863-91 CARBON 22K 5% 1/4W
R721 1-247-847-91 CARBON 4.7K 5% 1/4W
R722 1-247-847-91 CARBON 4.7K 5% 1/4W
R723 1-247-847-91 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-247-831-91 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-847-91 CARBON 4.7K 5% 1/4W
*************************************************************
A-1099-771-A DVD SURR BOARD, COMPLETE (E2, MX)
A-1099-850-A DVD SURR BOARD, COMPLETE
(GNV99D: EXCEPT TH)
A-1114-979-A DVD SURR BOARD, COMPLETE
(GNV111D: EXCEPT E2, MX, TH)
A-1124-096-A DVD SURR BOARD, COMPLETE (GNV111D: TH)
A-1124-108-A DVD SURR BOARD, COMPLETE (GNV99D: TH)
***************
< CAPACITOR >
C700 1-126-963-11 ELECT 4.7uF 20% 50V
C701 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C702 1-126-923-91 ELECT 220uF 20% 10V
C703 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C704 1-126-963-11 ELECT 4.7uF 20% 50V
C710 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
(GNV111D)
C710 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
(GNV99D)
C711 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
(GNV111D)
C711 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
(GNV99D)
C712 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
(GNV111D)
C712 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
(GNV99D)
C721 1-126-965-91 ELECT 22uF 20% 50V
(GNV111D)
C730 1-136-495-11 FILM 0.068uF 5% 50V
C731 1-136-495-11 FILM 0.068uF 5% 50V
C732 1-131-992-91 CERAMIC CHIP 100000PF 35V
C733 1-131-992-91 CERAMIC CHIP 100000PF 35V
C740 1-126-963-11 ELECT 4.7uF 20% 50V
C741 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C742 1-126-923-91 ELECT 220uF 20% 10V
C743 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C744 1-126-963-11 ELECT 4.7uF 20% 50V
C746 1-126-963-11 ELECT 4.7uF 20% 50V
(GNV111D)
C747 1-126-963-11 ELECT 4.7uF 20% 50V
(GNV111D)
C748 1-104-658-91 ELECT 100uF 20% 10V
(GNV111D)
C749 1-126-963-11 ELECT 4.7uF 20% 50V
(GNV111D)
C750 1-126-963-11 ELECT 4.7uF 20% 50V
C751 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C752 1-126-923-91 ELECT 220uF 20% 10V
C753 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C754 1-126-963-11 ELECT 4.7uF 20% 50V
C755 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(GNV111D)
C756 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(GNV111D)
C757 1-131-992-91 CERAMIC CHIP 100000PF 35V
(GNV111D)
C758 1-126-963-11 ELECT 4.7uF 20% 50V
(GNV111D)
C759 1-126-964-11 ELECT 10uF 20% 50V
(GNV111D)
C770 1-136-495-11 FILM 0.068uF 5% 50V
C771 1-136-495-11 FILM 0.068uF 5% 50V
C772 1-131-992-91 CERAMIC CHIP 100000PF 35V
C773 1-131-992-91 CERAMIC CHIP 100000PF 35V
C780 1-136-495-11 FILM 0.068uF 5% 50V
C781 1-136-495-11 FILM 0.068uF 5% 50V
C782 1-131-992-91 CERAMIC CHIP 100000PF 35V
C783 1-131-992-91 CERAMIC CHIP 100000PF 35V
C791 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C792 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C793 1-128-563-11 ELECT 100uF 20% 100V
C794 1-128-563-11 ELECT 100uF 20% 100V
C795 1-128-560-11 ELECT 22uF 20% 100V
C796 1-128-560-11 ELECT 22uF 20% 100V
DRIVER DVD SURR
Ver. 1.1
