85
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNV99D/GNV111D
R760 1-216-809-11 METAL CHIP 100 5% 1/10W
(GNV111D)
R761 1-216-839-11 METAL CHIP 33K 5% 1/10W
(GNV99D)
R761 1-216-845-11 METAL CHIP 100K 5% 1/10W
(GNV111D)
R762 1-216-839-11 METAL CHIP 33K 5% 1/10W
(GNV99D)
R762 1-216-845-11 METAL CHIP 100K 5% 1/10W
(GNV111D)
R764 1-260-087-11 CARBON 100 5% 1/2W
R765 1-260-087-11 CARBON 100 5% 1/2W
R766 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R767 1-216-837-11 METAL CHIP 22K 5% 1/10W
R768 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R769 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R770 1-234-499-21 ENCAPSULATED COMPONENT
R771 1-216-821-11 METAL CHIP 1K 5% 1/10W
R772 1-216-838-11 METAL CHIP 27K 5% 1/10W
R773 1-216-845-11 METAL CHIP 100K 5% 1/10W
R774 1-216-843-11 METAL CHIP 68K 5% 1/10W
R775 1-245-711-31 CARBON 10 5% 1/2W
R776 1-245-711-31 CARBON 10 5% 1/2W
R777 1-245-711-31 CARBON 10 5% 1/2W
R778 1-216-841-11 METAL CHIP 47K 5% 1/10W
(GNV111D)
R779 1-216-841-11 METAL CHIP 47K 5% 1/10W
(GNV111D)
0 R780 1-234-499-21 ENCAPSULATED COMPONENT
R781 1-216-821-11 METAL CHIP 1K 5% 1/10W
R782 1-216-838-11 METAL CHIP 27K 5% 1/10W
R783 1-216-845-11 METAL CHIP 100K 5% 1/10W
R784 1-216-841-11 METAL CHIP 47K 5% 1/10W
R785 1-245-711-31 CARBON 10 5% 1/2W
R786 1-245-711-31 CARBON 10 5% 1/2W
R787 1-245-711-31 CARBON 10 5% 1/2W
R788 1-216-841-11 METAL CHIP 47K 5% 1/10W
(GNV111D)
R792 1-216-839-11 METAL CHIP 33K 5% 1/10W
(GNV99D)
R792 1-216-845-11 METAL CHIP 100K 5% 1/10W
(GNV111D)
0 R793 1-217-637-00 FUSIBLE 1 5% 1/4W
0 R794 1-245-605-51 FUSIBLE 100 5% 1/4W
0 R795 1-245-605-51 FUSIBLE 100 5% 1/4W
R796 1-215-872-11 METAL OXIDE 3.3K 5% 1W
(GNV111D)
R797 1-216-837-11 METAL CHIP 22K 5% 1/10W
R798 1-216-821-11 METAL CHIP 1K 5% 1/10W
R799 1-215-872-11 METAL OXIDE 3.3K 5% 1W
(GNV111D)
< RELAY >
RY760 1-755-500-11 RELAY
RY761 1-755-500-11 RELAY
< TERMINAL >
TM700 1-780-001-21 TERMINAL BOARD (SPEAKER)
(CENTER SPEAKER)
TM701 1-780-170-21 TERMINAL BOARD (SPEAKER)
(SURR SPEAKER)
*************************************************************
JOG BOARD
**********
< CAPACITOR >
C1150 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CNS903 1-562-573-11 SOCKET, CONNECTOR 8P
< DIODE >
D919 8-719-071-44 DIODE SELS5223C-TP15 (VOL 2)
D920 8-719-071-44 DIODE SELS5223C-TP15 (VOL 3)
D921 8-719-071-44 DIODE SELS5223C-TP15 (VOL 4)
D922 8-719-071-44 DIODE SELS5223C-TP15 (VOL 5)
D923 8-719-071-44 DIODE SELS5223C-TP15 (VOL 6)
D924 8-719-071-44 DIODE SELS5223C-TP15 (VOL 1)
< JUMPER RESISTOR >
JR904 1-216-296-11 SHORT CHIP 0
JR905 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q911 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q912 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q913 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1138 1-216-820-11 METAL CHIP 820 5% 1/10W
R1139 1-216-820-11 METAL CHIP 820 5% 1/10W
R1140 1-216-820-11 METAL CHIP 820 5% 1/10W
R1144 1-216-820-11 METAL CHIP 820 5% 1/10W
R1145 1-216-820-11 METAL CHIP 820 5% 1/10W
R1146 1-216-820-11 METAL CHIP 820 5% 1/10W
R1156 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1157 1-216-820-11 METAL CHIP 820 5% 1/10W
R1158 1-216-820-11 METAL CHIP 820 5% 1/10W
R1159 1-216-820-11 METAL CHIP 820 5% 1/10W
R1190 1-216-809-11 METAL CHIP 100 5% 1/10W
R1191 1-216-809-11 METAL CHIP 100 5% 1/10W
R1192 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S1161 1-479-203-11 ENCODER (ROTARY) (OPERATION DIAL)
*************************************************************
DVD SURR JOG
Ver. 1.1
