94
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNV99D/GNV111D
R1123 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1125 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1126 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1127 1-218-839-11 METAL CHIP 33K 0.5% 1/10W
R1128 1-218-839-11 METAL CHIP 33K 0.5% 1/10W
R1130 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1131 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1132 1-216-864-11 SHORT CHIP 0
< VARIABLE RESISTOR >
RV1100 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV1101 1-227-452-11 RES, VAR, CARBON 50K (ECHO LEVEL)
*************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
*************************************************************
1-687-134-12 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
A-1089-532-A PA BOARD, COMPLETE (GNV99D: EXCEPT TH)
A-1089-591-A PA BOARD, COMPLETE (E2, MX)
A-1113-624-A PA BOARD, COMPLETE (GNV111D: TH)
A-1114-756-A PA BOARD, COMPLETE (GNV111D: EXCEPT TH)
A-1114-765-A PA BOARD, COMPLETE (GNV99D: TH)
*********
< CAPACITOR >
C600 1-126-963-11 ELECT 4.7uF 20% 50V
C601 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C602 1-126-923-91 ELECT 220uF 20% 10V
C604 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C605 1-131-992-91 CERAMIC CHIP 0.1uF 35V
C606 1-131-992-91 CERAMIC CHIP 0.1uF 35V
C608 1-126-965-91 ELECT 22uF 20% 50V
C609 1-128-560-11 ELECT 22uF 20% 100V
C610 1-128-560-11 ELECT 22uF 20% 100V
C616 1-136-495-11 FILM 0.068uF 5% 50V
C617 1-136-495-11 FILM 0.068uF 5% 50V
C618 1-128-582-11 ELECT 10uF 20% 100V
C619 1-128-582-11 ELECT 10uF 20% 100V
C634 1-104-665-11 ELECT 100uF 20% 25V
C635 1-104-665-11 ELECT 100uF 20% 25V
C636 1-107-721-11 ELECT 4.7uF 20% 100V
C637 1-107-721-11 ELECT 4.7uF 20% 100V
C648 1-104-658-91 ELECT 100uF 20% 10V
C649 1-126-964-11 ELECT 10uF 20% 50V
C650 1-126-963-11 ELECT 4.7uF 20% 50V
C651 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C652 1-126-923-91 ELECT 220uF 20% 10V
C654 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C655 1-126-964-11 ELECT 10uF 20% 50V
C656 1-127-815-11 ELECT 3300uF 20% 100V
C657 1-130-777-00 MYLAR 0.1uF 5% 100V
C658 1-112-032-11 ELECT 4700uF 20% 63V
C659 1-130-777-00 MYLAR 0.1uF 5% 100V
C660 1-131-992-91 CERAMIC CHIP 100000PF 35V
C666 1-136-495-11 FILM 0.068uF 5% 50V
C667 1-136-495-11 FILM 0.068uF 5% 50V
C676 1-127-815-11 ELECT 3300uF 20% 100V
C677 1-130-777-00 MYLAR 0.1uF 5% 100V
C678 1-112-032-11 ELECT 4700uF 20% 63V
C679 1-130-777-00 MYLAR 0.1uF 5% 100V
C683 1-131-992-91 CERAMIC CHIP 0.1uF 35V
C693 1-131-992-91 CERAMIC CHIP 0.1uF 35V
< CONNECTOR >
CN600 1-764-865-41 CONNECTOR, BOARD TO BOARD 13P
CN601 1-784-031-41 CONNECTOR, BOARD TO BOARD 8P
* CN602 1-564-512-11 PLUG, CONNECTOR 9P
< DIODE >
D609 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-056-93 DIODE UDZ-TE-17-18B
D612 8-719-056-93 DIODE UDZ-TE-17-18B
D620 8-719-988-61 DIODE 1SS355TE-17
D624 8-719-988-61 DIODE 1SS355TE-17
D646 8-719-988-61 DIODE 1SS355TE-17
D654 8-719-988-61 DIODE 1SS355TE-17
D655 8-719-988-61 DIODE 1SS355TE-17
D660 8-719-988-61 DIODE 1SS355TE-17
D661 8-719-988-61 DIODE 1SS355TE-17
D670 8-719-988-61 DIODE 1SS355TE-17
D656 8-719-066-42 DIODE RBV1306 (GNV99D)
D656 8-719-073-32 DIODE D25XB60 (GNV111D)
D658 8-719-066-42 DIODE RBV1306 (GNV111D)
D658 8-719-500-60 DIODE D5SBA20 (GNV99D)
< IC >
IC600 6-600-169-01 IC STK412-240
< JUMPER RESISTOR >
JR600 1-216-296-11 SHORT CHIP 0
JR603 1-216-296-11 SHORT CHIP 0
< COIL >
L680 1-420-872-52 COIL, AIR-CORE
L690 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q604 8-729-924-99 TRANSISTOR 2SC3722K-E
Q606 8-729-821-00 TRANSISTOR 2SA1207
Q610 8-729-924-99 TRANSISTOR 2SC3722K-E
Q618 8-729-924-99 TRANSISTOR 2SC3722K-E
Q628 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q629 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q630 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q634 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q640 8-729-802-80 TRANSISTOR 2SC3661
Q641 8-729-802-80 TRANSISTOR 2SC3661
MOTOR (LD) MOTOR (TB) PAMIC
Ver. 1.1
