NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 78 —
SECTION 9
ELECTRICAL PARTS LIST
• Abbreviation
CND : Canadian model
AUS : Australian model
G : German model
AED : North European model
EA : Saudi Arabia model
E2 : Central and South America model
E3 : Middle and Near East model
MX : Mexican model
SP : Singapore model
TH : Thai model
TW : Taiwan model
AR : Argentina model
KR : Korea model
5 1-672-969-11 AC SEC BOARD
************
1-533-217-31 HOLDER, FUSE (GRX30/GRX30J)
< CONNECTOR >
CN21 1-564-524-11 PLUG, CONNECTOR 9P (R550/RXD5)
* CN21 1-564-526-11 PLUG, CONNECTOR 11P (GRX30/GRX30J)
< FUSE >
! F953 1-532-506-31 FUSE (6.3A 250V) (GRX30/GRX30J)
! F954 1-532-506-31 FUSE (6.3A 250V) (GRX30/GRX30J)
! F955 1-532-504-31 FUSE (4.0A 250V) (GRX30/GRX30J)
! F956 1-532-504-31 FUSE (4.0A 250V) (GRX30/GRX30J)
< RESISTOR >
! R951 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
! R952 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(GRX30/GRX30J)
! R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(R550/RXD5)
************************************************************
* A-2007-731-A AUDIO BOARD, COMPLETE
*********************
< CAPACITOR >
C301 1-162-289-31 CERAMIC 390PF 10% 50V
C302 1-126-968-11 ELECT 100uF 20% 6.3V
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C304 1-130-483-00 MYLAR 0.01uF 5% 50V
C305 1-107-715-11 ELECT 22uF 20% 16V
C311 1-162-289-31 CERAMIC 390PF 10% 50V
C313 1-162-282-31 CERAMIC 100PF 10% 50V
C314 1-130-487-00 MYLAR 0.022uF 5% 50V
C315 1-126-233-11 ELECT 22uF 20% 50V
C331 1-137-427-11 FILM 120PF 5% 50V
C332 1-162-288-31 CERAMIC 330PF 10% 50V
C333 1-162-209-31 CERAMIC 27PF 5% 50V
C401 1-162-289-31 CERAMIC 390PF 10% 50V
C402 1-126-968-11 ELECT 100uF 20% 6.3V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-130-483-00 MYLAR 0.01uF 5% 50V
C405 1-107-715-11 ELECT 22uF 20% 16V
C411 1-162-289-31 CERAMIC 390PF 10% 50V
C413 1-162-282-31 CERAMIC 100PF 10% 50V
C414 1-130-487-00 MYLAR 0.022uF 5% 50V
C415 1-126-233-11 ELECT 22uF 20% 50V
C431 1-137-427-11 FILM 120PF 5% 50V
C432 1-162-288-31 CERAMIC 330PF 10% 50V
C433 1-162-209-31 CERAMIC 27PF 5% 50V
C601 1-104-396-11 ELECT 10uF 20% 16V
C602 1-104-396-11 ELECT 10uF 20% 16V
C611 1-104-396-11 ELECT 10uF 20% 16V
C612 1-104-396-11 ELECT 10uF 20% 16V
C621 1-137-150-11 FILM 0.01uF 5% 100V
C622 1-126-961-11 ELECT 2.2uF 20% 50V
C623 1-136-155-00 FILM 0.015uF 5% 50V
C624 1-130-481-00 MYLAR 0.0068uF 5% 50V
C625 1-130-481-00 MYLAR 0.0068uF 5% 50V
C627 1-124-903-11 ELECT 1uF 20% 50V
C628 1-136-153-00 FILM 0.01uF 5% 50V
C642 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN601 1-568-834-11 SOCKET, CONNECTOR 15P
< IC >
IC601 8-759-111-44 IC UPC4570C-1
IC602 8-759-143-54 IC UPC1330HA
IC611 8-759-111-44 IC UPC4570C-1
< COIL >
L331 1-410-780-11 INDUCTOR 27mH
L431 1-410-780-11 INDUCTOR 27mH
L601 1-414-193-41 INDUCTOR 220uH
L602 1-414-193-41 INDUCTOR 220uH
AC SEC AUDIO
