Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 80 —
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
< RESISTOR >
R101 1-216-077-00 METAL CHIP 15K 5% 1/10W
R102 1-216-097-91 RES,CHIP 100K 5% 1/10W
R103 1-216-077-00 METAL CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-073-00 METAL CHIP 10K 5% 1/10W
R106 1-216-049-91 RES,CHIP 1K 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-121-91 RES,CHIP 1M 5% 1/10W
R110 1-216-025-91 RES,CHIP 100 5% 1/10W
R111 1-216-121-91 RES,CHIP 1M 5% 1/10W
R113 1-216-121-91 RES,CHIP 1M 5% 1/10W
R114 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-049-91 RES,CHIP 1K 5% 1/10W
R119 1-216-041-00 METAL CHIP 470 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-91 RES,CHIP 100K 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES,CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-00 METAL CHIP 15K 5% 1/10W
R181 1-216-078-00 RES,CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-00 METAL CHIP 15K 5% 1/10W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
RN102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
1-672-968-11 CD SW BOARD
************
< DIODE >
D751 8-719-056-13 DIODE SML79423C-TP15
D752 8-719-056-13 DIODE SML79423C-TP15
D753 8-719-056-13 DIODE SML79423C-TP15
D754 8-719-063-93 DIODE SLR325VC-N-T32
< TRANSISTOR >
Q751 8-729-904-39 TRANSISTOR DTC114TS
Q752 8-729-904-39 TRANSISTOR DTC114TS
Q753 8-729-904-39 TRANSISTOR DTC114TS
< RESISTOR >
R751 1-249-418-11 CARBON 1.2K 5% 1/4W F
R752 1-249-420-11 CARBON 1.8K 5% 1/4W F
R753 1-249-422-11 CARBON 2.7K 5% 1/4W F
R754 1-247-843-11 CARBON 3.3K 5% 1/4W
R755 1-249-425-11 CARBON 4.7K 5% 1/4W F
R756 1-249-427-11 CARBON 6.8K 5% 1/4W F
R757 1-249-429-11 CARBON 10K 5% 1/4W
R758 1-247-804-11 CARBON 75 5% 1/4W
R759 1-247-804-11 CARBON 75 5% 1/4W
R760 1-247-804-11 CARBON 75 5% 1/4W
R761 1-247-804-11 CARBON 75 5% 1/4W
R762 1-247-804-11 CARBON 75 5% 1/4W
R763 1-247-804-11 CARBON 75 5% 1/4W
R764 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S751 1-762-196-21 SWITCH, TACT (1/u)
S752 1-762-196-21 SWITCH, TACT ((STANBY),DEMO)
S753 1-762-196-21 SWITCH, TACT (DISC 1)
S754 1-762-196-21 SWITCH, TACT (DISC 2)
S755 1-762-196-21 SWITCH, TACT (DISC 3)
S756 1-762-196-21 SWITCH, TACT (DISC SKIP,EX-CHANGE)
S757 1-762-196-21 SWITCH, TACT (6)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
BD CD SW CONNECTOR LEAF SW
