Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 87 —
R857 1-249-441-11 CARBON 100K 5% 1/4W
! R858 1-220-755-11 METAL 0.22 10% 2W
(AEP,AED,UK,G,CIS)
! R858 1-220-893-11 METAL 0.22 10% 5W
(EXCEPT AEP,AED,UK,G,CIS)
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-419-11 CARBON 1.5K 5% 1/4W F
(TH)
R860 1-247-759-11 CARBON 3.9K 5% 1/2W
(EXCEPT TH/GRX30J)
R861 1-212-881-11 FUSIBLE 100 5% 1/4W F
R865 1-249-435-11 CARBON 33K 5% 1/4W
R866 1-249-435-11 CARBON 33K 5% 1/4W
! R870 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
(TH)
R871 1-249-429-11 CARBON 10K 5% 1/4W
(TH)
R872 1-247-843-11 CARBON 3.3K 5% 1/4W
(GRX30/GRX30J)
R873 1-219-121-11 FUSIBLE 0.22 5% 1/4W
(EXCEPT TH/R550/RXD5)
R892 1-249-437-11 CARBON 47K 5% 1/4W
R901 1-247-843-11 CARBON 3.3K 5% 1/4W
R902 1-249-415-11 CARBON 680 5% 1/4W F
R903 1-249-419-11 CARBON 1.5K 5% 1/4W F
R904 1-249-414-11 CARBON 560 5% 1/4W F
R905 1-249-425-11 CARBON 4.7K 5% 1/4W F
R906 1-247-843-11 CARBON 3.3K 5% 1/4W
R907 1-249-415-11 CARBON 680 5% 1/4W F
R908 1-249-429-11 CARBON 10K 5% 1/4W
R909 1-249-430-11 CARBON 12K 5% 1/4W
R911 1-249-409-11 CARBON 220 5% 1/4W F
R920 1-249-383-11 CARBON 1.5 5% 1/6W F
R921 1-249-383-11 CARBON 1.5 5% 1/6W F
R931 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
< RELAY >
RY401 1-515-920-1 RELAY
< TERMINAL >
TM401 1-694-302-11 TERMINAL BOARD (CHECKER PIN)
(SPEAKER)(CIS)
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(SPEAKER)(US,CND/GRX30/GRX30J)
TM401 1-537-925-41 TERMINAL BOARD (CHECKER PIN)
(SPEAKER)(AEP,AED,UK,G)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (32.768kHz)
X613 1-781-107-21 VIBRATOR, SERAMIC (16.0MHz)
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C
(US,CND,CIS/GRX30/GRX30J)
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN703 1-785-550-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
(US,CND,CIS/GRX30/GRX30J)
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
MAIN MOTOR (SLIDE) MOTOR (TURN)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
