Sony HCD-GRX30 - ST-BY Board Parts List

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 91 —
< RELAY >
! RY11 1-755-276-11 RELAY, POWER (R550/RXD5)
< TRANSFORMER >
! T901 1-433-763-21 TRANSFORMER, POWER (AEP,AED,UK,G)
! T901 1-433-763-11 TRANSFORMER, POWER (CIS)
! T901 1-433-764-11 TRANSFORMER, POWER (US,CND)
< SWITCH >
VS901 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)(GRX30:E2,E3,EA,AR,SP,TW/GRX30J)
************************************************************
MISCELLANEOUS
*************
10 1-773-043-11 WIRE (FLAT TYPE) (17 CORE)
11 1-773-024-11 WIRE (FLAT TYPE) (15 CORE)
108 1-769-976-11 WIRE (FLAT TYPE) (13 CORE)
(E2,MX,AR,TH,KR,AUS,US,CND)
108 1-773-008-11 WIRE (FLAT TYPE) (15 CORE)
(E3,EA,SP,TW,AEP,AED,UK,G,CIS)
108 1-773-011-11 WIRE (FLAT TYPE) (15 CORE) (GRX30J)
109 1-233-544-11 TUNER (FM/AM) (US,CND)
109 1-233-545-14 TUNER (FM/AM) (MX,AR,TH,KR,AUS)
109 1-233-546-11 TUNER (FM/MW/SW)
(GRX30:E3,EA,SP,TW/GRX30J)
109 1-693-443-11 TUNER (FM/AM) (AEP,AED,UK,G,CIS)
109 1-693-453-11 TUNER (FM/AM) (E2)
! 114 1-575-651-11 CORD, POWER
(GRX30:EA,AR,SP,TW/R550:CIS/RXD5:CIS)
! 114 1-575-653-11 CORD, POWER (GRX30:E2,E3,MX,TH/GRX30J)
! 114 1-696-847-11 CORD, POWER (GRX30:AUS)
! 114 1-769-079-21 CORD, POWER (GRX30:KR)
! 114 1-775-787-71 CORD, POWER
(R550:AEP,AED,UK,G/RXD5:AEP,AED,UK,G)
! 114 1-783-820-11 CORD, POWER (RXD5:US)
115 1-569-007-11 ADAPTOR, CONVERSION 2P
(GRX30:E3/GRX30J)
115 1-569-008-21 ADAPTOR, CONVERSION 2P
(GRX30:EA,AR,SP,TW)
115 1-569-008-31 ADAPTOR, CONVERSION
(GRX30:EA,AR,SP,TW)
115 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P
(R550:UK/RXD5:UK)
206 1-658-577-11 MOTOR (TURN) BOARD
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! F951 1-532-503-31 FUSE (T1.6AL 250V)
(R550/RXD5:AEP,AED,UK,G,CIS)
! F951 1-532-465-31 FUSE (T3.15AL 250V)
(GRX30:E2,E3,EA,MX,AR,SP,TW/GRX30J)
! F951 1-576-109-11 FUSE (5.0A 125V) (RXD5:US,CND)
! F953 1-532-506-31 FUSE (6.3A 250V) (GRX30/GRX30J)
! F954 1-532-506-31 FUSE (6.3A 250V) (GRX30/GRX30J)
! F955 1-532-504-31 FUSE (4.0A 250V) (GRX30/GRX30J)
! F956 1-532-504-31 FUSE (4.0A 250V) (GRX30/GRX30J)
M801 A-4672-004-A MOTOR ASSY
(GRX30/GRX30J/R550:CIS/RXD5:US,CND,CIS)
M801 A-4672-312-A MOTOR (CDM) ASSY
(R550:AEP,AED,UK,G/RXD5:AEP,AED,UK,G)
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAT ADDRESS DET)
! T11 1-433-755-11 TRANSFORMER, POWER (CIS)
! T11 1-433-755-21 TRANSFORMER, POWER (AEP,AED,UK,G)
! T11 1-433-756-11 TRANSFORMER, POWER (CND)
! T11 1-433-757-11 TRANSFORMER, POWER (US)
! T11 1-433-902-11 TRANSFORMER, POWER (GRX30/GRX30J)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-872-09 SCREW +BVTT 3 × 8 (S)
#2 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3 × 10 TYPE2 N-S
#5 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#7 7-685-851-04 SCREW +BVTT 2 × 4 (S)
#8 7-621-775-10 SCREW +B 2.6 × 4
#9 7-621-255-15 SCREW +PS 2.6 × 6
#11 7-628-254-15 SCREW +PS 2.6 × 6
#12 7-628-254-50 SCREW +PS 2.6 × 16
#13 7-685-853-04 SCREW +BVTT 2 × 6 (S)
#14 7-685-861-01 SCREW +BVTT 2.6 × 5 (S)
#16 7-682-953-09 SCREW +PSW 3 × 20
(GRX30:E2,E3,EA,MX,AR,SP,TW,KR,AUS/GRX30J/R550/RXD5)
#17 3-030-823-01 SCREW (+BVTT) (2 × 3.5)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
ST-BY
