Sony HCD-LV80 - 3-3. SUB PANEL; 3-4. CD LID ASSEMBLY; 3-5. TAPE MECHANISM DECK AND CASSETTE LID

12
3-3. SUB PANEL
3-4. CD LID ASSEMBLY
1CD lid assembl
y
3 Sab panel assembly
2Spring(CD lid)
3-5. TAPE MECHANISM DECK AND CASSETTE LID
1Two screws(BVTP3x8)
4Mechanism deck
5Two screws
(BVTP3x8)
2Screw(BVTP3x8)
7Screw
(BVTP3x8)
qaSpring(deck B)
9Spring(TC- lid)
8Spring(TC- lid)
0Bracket
qdSpring(deck A)
qfHolder(deck A)
qsHolder(deck B)
3Screw(BVTP3x8
)
6Screw(BVTP3x8)
5Five screws
(BVTP2.6x8)
1Three screws
(BVTP2.6x8)
6Screw
(BVTP2.6x8)
7Screw
(BVTP2.6x8)
2Ornamental
plate
8Four screws
(BVTP2.6x8)
9Front input boar
d
0Sub panel block
4Connector
(CN703)
3Connector
(CN812)
Claw
