Sony HCD-LV80 - 8-5. TC MECHANISM SECTION 1 (TCM230 PWR12)

70
8-5. TC MECHANISM SECTION 1 (TCM230PWR12)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
407 3-017-366-01 BASE (PINCH LEVER REV)
408 3-016-567-02 SPRING (CASSETTE), LEAF
409 A-2007-849-A AUDIO BOARD, COMPLETE
HP101 A-2004-765-A BASE (A) ASSY, HEAD
HRPE10 A-2004-766-A BASE (B) ASSY, HEAD
401 3-376-464-11 SCREW(+PTT 2.6X6),GROUND POINT
402 3-911-116-42 RIVET, PUSH
403 3-016-574-01 SPRING (HEAD), TENSION
404 X-3374-156-4 PINCH LEVER (REV) ASSY
405 X-3374-155-4 PINCH LEVER (FWD) ASSY
406 3-017-365-01 BASE (PINCH LEVER FWD)
401
402
402
403
403
404
404
405
405
406
406
407
408
408
407
HRPE101
HP101
409
