SECTION 9
ELECTRICAL PARTS LIST
Note:
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AUDIO
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
SP : Singapore model
EA : Saudi Arabia model
MY : Malaysia model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
When indicating parts by reference
number, please include the board
name.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
A-2007-849-A AUDIO BOARD, COMPLETE
********************
< CAPACITOR >
C301 1-162-289-31 CERAMIC 390PF 10.00% 50V
C302 1-126-968-11 ELECT 100uF 20.00% 6.3V
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C304 1-130-483-00 MYLAR 0.01uF 5% 50V
C305 1-107-715-11 ELECT 22uF 20.00% 16V
C311 1-162-289-31 CERAMIC 390PF 10.00% 50V
C313 1-162-282-31 CERAMIC 100PF 10% 50V
C314 1-130-487-00 MYLAR 0.022uF 5% 50V
C315 1-126-233-11 ELECT 22uF 20% 50V
C331 1-137-427-11 MYLAR 120PF 5.00% 50V
C332 1-162-288-31 CERAMIC 330PF 10% 50V
C333 1-162-209-31 CERAMIC 27PF 5.00% 50V
C401 1-162-289-31 CERAMIC 390PF 10.00% 50V
C402 1-126-968-11 ELECT 100uF 20.00% 6.3V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-130-483-00 MYLAR 0.01uF 5% 50V
C405 1-107-715-11 ELECT 22uF 20.00% 16V
C411 1-162-289-31 CERAMIC 390PF 10.00% 50V
C413 1-162-282-31 CERAMIC 100PF 10% 50V
C414 1-130-487-00 MYLAR 0.022uF 5% 50V
C415 1-126-233-11 ELECT 22uF 20% 50V
C431 1-136-434-11 FILM 120PF 5.00% 630V
C432 1-162-288-31 CERAMIC 330PF 10% 50V
C433 1-162-209-31 CERAMIC 27PF 5.00% 50V
C601 1-104-396-11 ELECT 10uF 20.00% 16V
C602 1-104-396-11 ELECT 10uF 20.00% 16V
C611 1-104-396-11 ELECT 10uF 20.00% 16V
C612 1-104-396-11 ELECT 10uF 20.00% 16V
C621 1-137-150-11 FILM 0.01uF 5.00% 100V
C622 1-126-961-11 ELECT 2.2uF 20.00% 50V
C623 1-136-155-00 FILM 0.015uF 5% 50V
C624 1-130-481-00 MYLAR 0.0068uF 5% 50V
C625 1-130-481-00 MYLAR 0.0068uF 5% 50V
C627 1-124-903-11 ELECT 1uF 20.00% 50V
C628 1-136-153-00 FILM 0.01uF 5% 50V
C642 1-104-664-11 ELECT 47uF 20.00% 16V
< CONNECTOR >
CN601 1-695-338-11 PIN, CONNECTOR (PC BOARD) 15P
< IC >
IC601 8-759-111-44 IC uPC4570C-1
IC602 8-759-143-54 IC uPC1330HA
IC611 8-759-111-44 IC uPC4570C-1
< COIL >
L331 1-410-780-11 INDUCTOR 27MH
L431 1-410-780-11 INDUCTOR 27MH
< TRANSISTOR >
Q621 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q622 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q623 8-729-801-93 TRANSISTOR 2SD1387-34-TP
< RESISTOR >
R301 1-247-881-00 CARBON 120K 5% 1/4W
R302 1-247-815-91 CARBON 220 5% 1/4W
R303 1-247-863-91 CARBON 22K 5% 1/4W
R304 1-247-889-00 CARBON 270K 5% 1/4W
R305 1-247-858-11 CARBON 13K 5% 1/4W
R311 1-247-881-00 CARBON 120K 5% 1/4W
R312 1-247-807-31 CARBON 100 5% 1/4W
R314 1-247-882-11 CARBON 130K 5% 1/4W
R315 1-247-850-11 CARBON 6.2K 5% 1/4W
R331 1-249-430-11 CARBON 12K 5% 1/4W
R401 1-247-881-00 CARBON 120K 5% 1/4W
R402 1-247-815-91 CARBON 220 5% 1/4W
R403 1-247-863-91 CARBON 22K 5% 1/4W
R404 1-247-889-00 CARBON 270K 5% 1/4W
R405 1-247-858-11 CARBON 13K 5% 1/4W
R411 1-247-881-00 CARBON 120K 5% 1/4W
R412 1-247-807-31 CARBON 100 5% 1/4W
R414 1-247-882-11 CARBON 130K 5% 1/4W
R415 1-247-850-11 CARBON 6.2K 5% 1/4W
R431 1-249-430-11 CARBON 12K 5% 1/4W
R601 1-247-815-91 CARBON 220 5% 1/4W
R602 1-247-815-91 CARBON 220 5% 1/4W
R608 1-247-815-91 CARBON 220 5% 1/4W
R609 1-247-863-91 CARBON 22K 5% 1/4W
R611 1-247-815-91 CARBON 220 5% 1/4W
R612 1-247-815-91 CARBON 220 5% 1/4W
0 R621 1-212-851-00 FUSIBLE 5.6 5% 1/4W
0 R622 1-212-851-00 FUSIBLE 5.6 5% 1/4W
