76
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R173 1-216-025-91 RES-CHIP 100 5% 1/10W
R175 1-216-025-91 RES-CHIP 100 5% 1/10W
R203 1-216-025-91 RES-CHIP 100 5% 1/10W
R204 1-216-025-91 RES-CHIP 100 5% 1/10W
R205 1-216-025-91 RES-CHIP 100 5% 1/10W
R206 1-216-295-91 SHORT 0
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT SW)
**************************************************************
* A-4673-765-A CD MOTOR BOARD, COMPLETE
***********************
* 4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20.00% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY) (UP SWITCH)
**************************************************************
A-4428-176-A CD-L BOARD, COMPLETE
*******************
< CAPACITOR >
C691 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN812 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE)6P
< DIODE >
D641 8-719-058-04 DIODE SEL5223S-TP15 (NON-STOP)
< RESISTOR >
R729 1-249-420-11 CARBON 1.8K 5% 1/4W F
R730 1-249-422-11 CARBON 2.7K 5% 1/4W F
R731 1-247-843-11 CARBON 3.3K 5% 1/4W
R732 1-249-425-11 CARBON 4.7K 5% 1/4W F
R733 1-249-427-11 CARBON 6.8K 5% 1/4W F
R734 1-249-429-11 CARBON 10K 5% 1/4W
R735 1-249-431-11 CARBON 15K 5% 1/4W
R736 1-249-434-11 CARBON 27K 5% 1/4W
R745 1-249-408-11 CARBON 180 5% 1/4W F
< SWITCH >
S651 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S652 1-762-875-21 SWITCH, KEYBOARD (NON-STOP)
S653 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S654 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S655 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S656 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S657 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S658 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
S659 1-762-875-21 SWITCH, KEYBOARD (FLASH)
S691 1-762-587-11 SWITCH, PUSH (1 KEY)(DOOR SW)
**************************************************************
A-4428-119-A CD-R BOARD, COMPLETE
********************
< CAPACITOR >
C613 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C614 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN703 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE)8P
< DIODE >
D700 8-719-056-13 DIODE SML79423C-TP15 (u)
< RESISTOR >
R737 1-249-420-11 CARBON 1.8K 5% 1/4W F
R738 1-249-422-11 CARBON 2.7K 5% 1/4W F
R739 1-247-843-11 CARBON 3.3K 5% 1/4W
R740 1-249-425-11 CARBON 4.7K 5% 1/4W F
R741 1-249-427-11 CARBON 6.8K 5% 1/4W F
R751 1-247-843-11 CARBON 3.3K 5% 1/4W
R752 1-249-425-11 CARBON 4.7K 5% 1/4W F
R753 1-249-427-11 CARBON 6.8K 5% 1/4W F
R754 1-249-429-11 CARBON 10K 5% 1/4W
R755 1-249-431-11 CARBON 15K 5% 1/4W
R756 1-249-434-11 CARBON 27K 5% 1/4W
R757 1-249-438-11 CARBON 56K 5% 1/4W
R758 1-249-403-11 CARBON 68 5% 1/4W F
R759 1-249-403-11 CARBON 68 5% 1/4W F
< SWITCH >
S667 1-762-875-21 SWITCH, KEYBOARD (NEXT)
S668 1-762-875-21 SWITCH, KEYBOARD (PREV)
S669 1-762-875-21 SWITCH, KEYBOARD (RETURN)
S670 1-762-875-21 SWITCH, KEYBOARD (SELECT)
S671 1-762-875-21 SWITCH, KEYBOARD (ACTIVE)
S676 1-762-875-21 SWITCH, KEYBOARD (M)
S677 1-762-875-21 SWITCH, KEYBOARD (u)
S678 1-762-875-21 SWITCH, KEYBOARD (m)
CD-L CD-RCD MOTORBD
