HCD-SX7/SX7B
6-5. LCD MODULE SECTION
201 3-077-331-21 +BV3 (3-CR) (L = 6 mm)
202 4-462-118-01 SHEET (NFC), ADHENSIVE
203 3-087-053-01 +BVTP2.6 (3CR) (L = 8 mm)
204 4-459-198-11 GASKET
205 3-704-515-22 SCREW (BV/RING) (L = 8 mm)
BT1 1-492-699-31 BLUETOOTH MODULE
FFC3 9-885-201-75 FY15 FFC (0.5 mm 10P BT)
FFC4 9-885-201-73 FY15 FFC (0.5 mm 6P NFC)
LCD1 1-812-067-21 LCD MODULE
NFC1 8-989-602-00 RC-S730 (WW) (NFC module)
#1 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
chassis section
204
201
201
201
201
205
not supplied
not supplied
not supplied
not supplied
#1
#1
NFC1
FFC4
LCD1
not supplied
202
201
201
203
BT1
FFC3
