Sony HCD-SX7 - Section 7 Electrical Parts List; Component Parts Listing

74
HCD-SX7/SX7B
SECTION 7
ELECTRICAL PARTS LIST
A-2066-338-A DAB BOARD, COMPLETE (SX7B)
********************
When the DAB board is defective, replace the complete mounted board.
*************************************************************
FRONT BOARD
************
< CAPACITOR >
C2002 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2004 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2006 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN2002 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< ROTARY ENCODER >
EN2001 1-480-109-11 ENCODER, ROTARY (Including NUT) (VOLUME)
EN2002 1-487-023-22 ROTARY ENCODER
(− TUNING +, . >, PUSH ENTER)
< IC >
IC2001 6-600-768-01 IC PNA4823M03S0 ( )
< JUMPER RESISTOR >
JR2001 1-216-864-91 SHORT CHIP 0
JR2002 1-216-864-91 SHORT CHIP 0
JR2003 1-216-864-91 SHORT CHIP 0
JR2004 1-216-864-91 SHORT CHIP 0
JR2005 1-216-864-91 SHORT CHIP 0
< RESISTOR >
R2001 1-216-805-11 METAL CHIP 47 5% 1/10W
R2003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2005 1-216-813-11 METAL CHIP 220 5% 1/10W
R2006 1-216-815-11 METAL CHIP 330 5% 1/10W
R2007 1-216-809-11 METAL CHIP 100 5% 1/10W
R2008 1-216-817-11 METAL CHIP 470 5% 1/10W
R2009 1-216-819-11 METAL CHIP 680 5% 1/10W
R2010 1-216-864-91 SHORT CHIP 0
R2019 1-216-864-91 SHORT CHIP 0
R2021 1-216-864-91 SHORT CHIP 0
< SWITCH >
S2001 1-762-875-21 SWITCH, KEYBOARD (BACK)
S2002 1-762-875-21 SWITCH, KEYBOARD (u)
S2003 1-762-875-21 SWITCH, KEYBOARD (MENU)
S2004 1-762-875-21 SWITCH, KEYBOARD (Z)
*************************************************************
A-2066-435-A MAIN BOARD, COMPLETE (SV) (SX7: AEP, UK)
(Type A) (See Note 1, 2)
A-2066-436-A MAIN BOARD, COMPLETE (SV) (SX7B: AEP, UK)
(Type A) (See Note 1, 2)
A-2074-704-A MAIN BOARD, COMPLETE (SV) (SX7: CND)
(See Note 1)
A-2074-705-A MAIN BOARD, COMPLETE (SV) (SX7B: AUS)
(See Note 1)
A-2081-436-A MAIN BOARD, COMPLETE (SV) (SX7: TH)
(See Note 1)
A-2081-437-A MAIN BOARD, COMPLETE (SV) (SX7: SP, IDN)
(See Note 1)
A-2081-439-A MAIN BOARD, COMPLETE (SV) (SX7: RU)
(See Note 1)
A-2081-440-A MAIN BOARD, COMPLETE (SV) (SX7: E32)
(See Note 1)
A-2081-441-A MAIN BOARD, COMPLETE (SV) (SX7: AR)
(See Note 1)
A-2179-743-A MAIN BOARD, COMPLETE (SV) (SX7: AEP, UK)
(Type B) (See Note 1, 2)
A-2179-756-A MAIN BOARD, COMPLETE (SV) (SX7B: AEP, UK)
(Type B) (See Note 1, 2)
********************
< CAPACITOR >
C002 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C003 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C004 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C005 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C006 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C007 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C008 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C009 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C010 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C011 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C013 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C015 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
* C016 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C017 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C018 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C019 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C022 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C024 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
Ver. 1.2
DAB
FRONT MAIN
Note 1: When the complete MAIN board is replaced, refer to
“CHECKING OF NETWORK CONNECTION” on page 5.
Note 2: Refer to “TYPE OF AEP AND UK MODELS” on page 6 for
Type of the AEP and UK models.
SYSSET
