Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
77
HCD-VX555/VX555J
R513 1-216-864-11 SHORT 0
R515 1-216-833-11 METAL CHIP 10K 5% 1/16W
R516 1-216-833-11 METAL CHIP 10K 5% 1/16W
R517 1-216-833-11 METAL CHIP 10K 5% 1/16W
R518 1-216-833-11 METAL CHIP 10K 5% 1/16W
R520 1-216-833-11 METAL CHIP 10K 5% 1/16W
R522 1-216-811-11 METAL CHIP 150 5% 1/16W
R523 1-216-864-11 SHORT 0
(EXCEPT VX555:EA/VX555J)
R523 1-216-821-11 METAL CHIP 1K 5% 1/16W
(VX555:EA/VX555J)
R529 1-216-809-11 METAL CHIP 100 5% 1/16W
R530 1-216-809-11 METAL CHIP 100 5% 1/16W
R532 1-216-841-11 METAL CHIP 47K 5% 1/16W
R541 1-216-841-11 METAL CHIP 47K 5% 1/16W
R543 1-216-809-11 METAL CHIP 100 5% 1/16W
R544 1-216-809-11 METAL CHIP 100 5% 1/16W
R545 1-216-809-11 METAL CHIP 100 5% 1/16W
R546 1-216-809-11 METAL CHIP 100 5% 1/16W
R547 1-216-809-11 METAL CHIP 100 5% 1/16W
R548 1-216-809-11 METAL CHIP 100 5% 1/16W
R549 1-216-809-11 METAL CHIP 100 5% 1/16W
R553 1-216-833-11 METAL CHIP 10K 5% 1/16W
R556 1-216-809-11 METAL CHIP 100 5% 1/16W
R557 1-216-809-11 METAL CHIP 100 5% 1/16W
R570 1-216-809-11 METAL CHIP 100 5% 1/16W
R573 1-216-833-11 METAL CHIP 10K 5% 1/16W
R574 1-216-833-11 METAL CHIP 10K 5% 1/16W
R575 1-216-833-11 METAL CHIP 10K 5% 1/16W
R576 1-216-841-11 METAL CHIP 47K 5% 1/16W
R577 1-216-841-11 METAL CHIP 47K 5% 1/16W
R578 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R579 1-216-817-11 METAL CHIP 470 5% 1/16W
R582 1-216-833-11 METAL CHIP 10K 5% 1/16W
R583 1-216-809-11 METAL CHIP 100 5% 1/16W
R584 1-216-809-11 METAL CHIP 100 5% 1/16W
R585 1-216-833-11 METAL CHIP 10K 5% 1/16W
R588 1-216-809-11 METAL CHIP 100 5% 1/16W
R589 1-216-809-11 METAL CHIP 100 5% 1/16W
R590 1-216-809-11 METAL CHIP 100 5% 1/16W
R591 1-216-809-11 METAL CHIP 100 5% 1/16W
R592 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(EXCEPT VX555J:JE)
R592 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(VX555J:JE)
R593 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(VX555:EA/VX555J:EA)
R593 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(VX555J:JE)
R804 1-216-841-11 METAL CHIP 47K 5% 1/16W
R821 1-216-841-11 METAL CHIP 47K 5% 1/16W
R822 1-216-842-11 METAL CHIP 56K 5% 1/16W
R823 1-216-833-11 METAL CHIP 10K 5% 1/16W
R824 1-216-841-11 METAL CHIP 47K 5% 1/16W
R825 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R826 1-216-839-11 METAL CHIP 33K 5% 1/16W
R827 1-216-837-11 METAL CHIP 22K 5% 1/16W
R829 1-216-837-11 METAL CHIP 22K 5% 1/16W
R830 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R831 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R841 1-216-837-11 METAL CHIP 22K 5% 1/16W
R842 1-216-837-11 METAL CHIP 22K 5% 1/16W
R843 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R845 1-216-857-11 METAL CHIP 1M 5% 1/16W
R854 1-216-841-11 METAL CHIP 47K 5% 1/16W
R861 1-216-821-11 METAL CHIP 1K 5% 1/16W
R862 1-216-833-11 METAL CHIP 10K 5% 1/16W
R863 1-216-841-11 METAL CHIP 47K 5% 1/16W
R864 1-216-821-11 METAL CHIP 1K 5% 1/16W
R865 1-216-821-11 METAL CHIP 1K 5% 1/16W
R866 1-216-806-11 RES-CHIP 56 5% 1/16W
R868 1-215-891-11 METAL OXIDE 680 5% 2W
R869 1-215-891-11 METAL OXIDE 680 5% 2W
R891 1-216-833-11 METAL CHIP 10K 5% 1/16W
R892 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R895 1-216-864-11 SHORT 0
0 R901 1-249-405-11 CARBON 100 5% 1/4W F
R911 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R912 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R914 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
0 R915 1-219-591-11 FUSIBLE 0.1 5% 1/2W
0 R916 1-219-119-11 FUSIBLE 0.1 5% 1/4W
R966 1-216-806-11 RES-CHIP 56 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB41 1-234-575-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV11 1-241-765-11 RES, ADJ, CARBON 22K
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
< RELAY >
RY801 1-755-372-11 RELAY
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-555-11 TERMINAL BOARD (4P) (ANTENNA)
TM801 1-694-635-11 TERMINAL BOARD (4P) (SPEAKER)
< VIBRATOR >
X51 1-760-549-31 VIBRATOR, CRYSTAL 4.5MHz
X501 1-567-098-41 VIBRATOR, CRYSTAL 32.768kHz
X502 1-781-107-21 VIBRATOR, SERAMIC 16MHz
************************************************************
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN
