Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
78
HCD-VX555/VX555J
1-680-265-11 MAIN TRANS BOARD
*****************
1-533-217-11 HOLDER, FUSE
< CAPACITOR >
C941 1-128-553-11 ELECT 220uF 20.00% 63V
C977 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN973 1-568-106-11 PIN, CONNECTOR 4P (EXCEPT VX555:TH)
CN973 1-564-321-00 PIN, CONNECTOR 2P (VX555:TH)
* CN977 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F971 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 F974 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0 F975 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
< RESISTOR >
0 R941 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R944 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
************************************************************
1-675-910-14 MOTOR BOARD
************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
************************************************************
A-2007-995-A PAD SWITCH BOARD, COMPLETE (VX555:IA)
A-4476-103-A PAD SWITCH BOARD, COMPLETE
(VX555:E,EA,MY,SP)
A-4476-597-A PAD SWITCH BOARD, COMPLETE (VX555J)
A-4476-627-A PAD SWITCH BOARD, COMPLETE (VX555:TH)
************************************
< CAPACITOR >
C751 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C752 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< DIODE >
D751 8-719-063-93 DIODE SLR325VC-N-T32 (REC)
D752 8-719-063-93 DIODE SLR325VC-N-T32 (ENTER)
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR BA1A4M-TP
Q752 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R750 1-249-410-11 CARBON 270 5% 1/4W F
R751 1-249-415-11 CARBON 680 5% 1/4W F
R752 1-249-411-11 CARBON 330 5% 1/4W
R754 1-249-410-11 CARBON 270 5% 1/4W F
R755 1-249-413-11 CARBON 470 5% 1/4W F
R756 1-249-414-11 CARBON 560 5% 1/4W F
R757 1-249-416-11 CARBON 820 5% 1/4W F
R758 1-249-417-11 CARBON 1K 5% 1/4W F
R759 1-249-418-11 CARBON 1.2K 5% 1/4W F
R760 1-249-419-11 CARBON 1.5K 5% 1/4W F
R761 1-249-421-11 CARBON 2.2K 5% 1/4W F
R762 1-249-422-11 CARBON 2.7K 5% 1/4W F
R763 1-249-424-11 CARBON 3.9K 5% 1/4W F
R764 1-249-426-11 CARBON 5.6K 5% 1/4W
R765 1-249-428-11 CARBON 8.2K 5% 1/4W F
R766 1-249-431-11 CARBON 15K 5% 1/4W
R767 1-249-434-11 CARBON 27K 5% 1/4W
R768 1-249-410-11 CARBON 270 5% 1/4W F
R769 1-249-413-11 CARBON 470 5% 1/4W F
R770 1-249-414-11 CARBON 560 5% 1/4W F
R771 1-249-416-11 CARBON 820 5% 1/4W F
R772 1-249-417-11 CARBON 1K 5% 1/4W F
R773 1-249-418-11 CARBON 1.2K 5% 1/4W F
R774 1-249-419-11 CARBON 1.5K 5% 1/4W F
R775 1-249-421-11 CARBON 2.2K 5% 1/4W F
R776 1-249-422-11 CARBON 2.7K 5% 1/4W F
R777 1-249-424-11 CARBON 3.9K 5% 1/4W F
R778 1-249-426-11 CARBON 5.6K 5% 1/4W
R779 1-249-428-11 CARBON 8.2K 5% 1/4W F
R780 1-249-431-11 CARBON 15K 5% 1/4W
R781 1-249-439-11 CARBON 68K 5% 1/4W
R790 1-249-434-11 CARBON 27K 5% 1/4W
< SWITCH >
S751 1-476-504-11 ENCODER, ROTARY (VOLUME)
S752 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S753 1-762-875-21 SWITCH, KEYBOARD (B)
S754 1-762-875-21 SWITCH, KEYBOARD (b)
S755 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S756 1-762-875-21 SWITCH, KEYBOARD (EFECT ON/OFF)
S757 1-762-875-21 SWITCH, KEYBOARD (GAME EQ)
S758 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON)
S759 1-762-875-21 SWITCH, KEYBOARD (PICTURE EFECT)
S760 1-762-875-21 SWITCH, KEYBOARD (m –)
S761 1-762-875-21 SWITCH, KEYBOARD (.)
S762 1-762-875-21 SWITCH, KEYBOARD (x)
S763 1-762-875-21 SWITCH, KEYBOARD (HI-DUB)
S764 1-762-875-21 SWITCH, KEYBOARD (REC)
S765 1-762-875-21 SWITCH, KEYBOARD (M +)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN TRANS MOTOR PAD SWITCH
