78
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R175 1-216-025-91 RES-CHIP 100 5% 1/10W
R180 1-216-097-91 RES-CHIP 100K 5% 1/10W
R181 1-216-100-00 RES-CHIP 130K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-081-00 METAL CHIP 22K 5% 1/10W
R184 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R185 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R186 1-216-081-00 METAL CHIP 22K 5% 1/10W
R187 1-216-081-00 METAL CHIP 22K 5% 1/10W
R188 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R189 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R190 1-216-081-00 METAL CHIP 22K 5% 1/10W
R191 1-216-081-00 METAL CHIP 22K 5% 1/10W
R192 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R193 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R194 1-216-295-91 SHORT 0
R203 1-216-025-91 RES-CHIP 100 5% 1/10W
R204 1-216-025-91 RES-CHIP 100 5% 1/10W
R205 1-216-025-91 RES-CHIP 100 5% 1/10W
R206 1-216-295-91 SHORT 0
R210 1-216-295-91 SHORT 0
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN SW)
**************************************************************
A-4428-661-A CD SW BOARD, COMPLETE (SP,MY,HK,EA)
***********************
A-4473-243-A CD SW BOARD, COMPLETE (TH)
***********************
< LED >
D661 8-719-058-64 LED SEL5823A-TP15 (1)
D662 8-719-058-64 LED SEL5823A-TP15 (2)
D663 8-719-058-64 LED SEL5823A-TP15 (3)
D664 8-719-058-64 LED SEL5823A-TP15 (4)
D665 8-719-058-64 LED SEL5823A-TP15 (5)
< RESISTOR >
R628 1-249-420-11 CARBON 1.8K 5% 1/4W F
R629 1-249-422-11 CARBON 2.7K 5% 1/4W F
R630 1-247-843-11 CARBON 3.3K 5% 1/4W
R631 1-249-425-11 CARBON 4.7K 5% 1/4W F
R632 1-249-427-11 CARBON 6.8K 5% 1/4W F
R633 1-249-429-11 CARBON 10K 5% 1/4W
R634 1-249-431-11 CARBON 15K 5% 1/4W
R635 1-249-434-11 CARBON 27K 5% 1/4W
R636 1-249-438-11 CARBON 56K 5% 1/4W
R661 1-249-409-11 CARBON 220 5% 1/4W F
R662 1-249-409-11 CARBON 220 5% 1/4W F
R663 1-249-409-11 CARBON 220 5% 1/4W F
R664 1-249-409-11 CARBON 220 5% 1/4W F
R665 1-249-409-11 CARBON 220 5% 1/4W F
< SWITCH >
S627 1-762-875-21 SWITCH, KEYBOARD (Z 5)
S628 1-762-875-21 SWITCH, KEYBOARD (Z 4)
S629 1-762-875-21 SWITCH, KEYBOARD (Z 3)
S630 1-762-875-21 SWITCH, KEYBOARD (Z 2)
S631 1-762-875-21 SWITCH, KEYBOARD (Z 1)
S632 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
S633 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S634 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S635 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S636 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
**************************************************************
1-671-507-11 CLAMP MOTOR BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C702 1-126-964-11 ELECT 10uF 20.00% 50V
C711 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN712 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-671-506-11 CONNECTOR BOARD
*****************
< CONNECTOR >
CN701 1-568-860-11 SOCKET, CONNECTOR 17P
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R707 1-249-424-11 CARBON 3.9K 5% 1/4W F
R708 1-249-417-11 CARBON 1K 5% 1/4W F
R709 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
A-4428-998-A FRONT AMP BOARD, COMPLETE
(SP,MY,HK,EA)
***************************
A-4473-272-A FRONT AMP BOARD, COMPLETE (TH)
***************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C801 1-126-963-11 ELECT 4.7uF 20.00% 50V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-104-664-11 ELECT 47uF 20.00% 10V
C806 1-136-495-11 MYLAR 0.068uF 5.00% 50V
FRONT AMPCONNECTORBD CD SW CLAMP MOTOR
