79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C807 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C811 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C812 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C821 1-107-721-11 ELECT 4.7uF 20.00% 100V
C822 1-107-717-11 ELECT 47uF 20.00% 50V
C837 1-126-963-11 ELECT 4.7uF 20.00% 50V
C851 1-126-963-11 ELECT 4.7uF 20.00% 50V
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-104-664-11 ELECT 47uF 20.00% 10V
C856 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C857 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C861 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C862 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C871 1-107-721-11 ELECT 4.7uF 20.00% 100V
C872 1-126-959-11 ELECT 0.47uF 20.00% 50V
C891 1-104-665-11 ELECT 100uF 20.00% 10V
C892 1-126-961-11 ELECT 2.2uF 20.00% 50V
C893 1-104-665-11 ELECT 100uF 20.00% 10V
C911 1-130-777-00 MYLAR 0.1uF 10.00% 100V
C912 1-130-777-00 MYLAR 0.1uF 10.00% 100V
C951 1-127-755-11 ELECT 3300uF 20% 100V
C952 1-127-755-11 ELECT 3300uF 20% 100V
C953 1-135-515-11 ELECT 3300uF 20% 50V
C954 1-135-515-11 ELECT 3300uF 20% 50V
C955 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C956 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C961 1-128-560-11 ELECT 22uF 20.00% 100V
C962 1-128-560-11 ELECT 22uF 20.00% 100V
C963 1-126-968-11 ELECT 100uF 20.00% 50V
C964 1-128-552-11 ELECT 47uF 20.00% 63V
C981 1-128-564-11 ELECT 220uF 20.00% 100V
C982 1-126-964-11 ELECT 10uF 20.00% 50V
C983 1-126-967-11 ELECT 47uF 20.00% 50V
C984 1-164-159-11 CERAMIC 0.1uF 50V
C991 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C992 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C993 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C994 1-136-165-00 MYLAR 0.1uF 5.00% 50V
< CONNECTOR >
CN801 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN803 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN911 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D802 8-719-911-19 DIODE 1SS133T-72
D821 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-911-19 DIODE 1SS133T-72
D871 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D911 8-719-060-53 DIODE RBV2506
D951 8-719-302-38 DIODE RBV-602-01
D961 8-719-947-58 DIODE MTZJ-T-72-13C
D962 8-719-947-58 DIODE MTZJ-T-72-13C
D963 8-719-911-19 DIODE 1SS133T-72
D981 8-719-024-99 DIODE 11ES2-NTA2B
D982 8-719-079-21 DIODE MTZJ-T-72-20D
D983 8-719-079-21 DIODE MTZJ-T-72-20D
D984 8-719-160-56 DIODE RD12F-T7B2
D991 8-719-024-99 DIODE 11ES2-NTA2B
D992 8-719-024-99 DIODE 11ES2-NTA2B
D993 8-719-024-99 DIODE 11ES2-NTA2B
D994 8-719-024-99 DIODE 11ES2-NTA2B
D995 8-719-975-85 DIODE 21DQ04N-TA2
D996 8-719-975-85 DIODE 21DQ04N-TA2
D997 8-719-975-85 DIODE 21DQ04N-TA2
D998 8-719-975-85 DIODE 21DQ04N-TA2
< TERMINAL >
* EPT951 1-537-738-21 TERMINAL, EARTH
< IC >
IC801 8-749-017-05 IC STK412-040
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q821 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q822 8-729-900-63 TRANSISTOR BN1F4M-TP
Q841 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q842 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q871 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q881 8-729-139-98 TRANSISTOR 2SA1175
Q883 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q891 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q892 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q893 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q894 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q895 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q896 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q897 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q961 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q962 8-729-140-82 TRANSISTOR 2SA1376-T-L
Q963 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q981 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-247-825-11 CARBON 560 5% 1/4W
R804 1-249-438-11 CARBON 56K 5% 1/4W
0R805 1-234-499-21 ENCAPSULATED COMPONENT
R806 1-249-417-11 CARBON 1K 5% 1/4W F
R807 1-249-431-11 CARBON 15K 5% 1/4W
R808 1-249-441-11 CARBON 100K 5% 1/4W
R809 1-260-076-11 CARBON 10 5% 1/2W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R815 1-249-437-11 CARBON 47K 5% 1/4W
R821 1-260-319-51 CARBON 180 5% 1/2W
R822 1-260-319-51 CARBON 180 5% 1/2W
R823 1-260-319-51 CARBON 180 5% 1/2W
R824 1-260-319-51 CARBON 180 5% 1/2W
FRONT AMP
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
