80
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R825 1-249-402-11 CARBON 56 5% 1/4W F
R826 1-249-417-11 CARBON 1K 5% 1/4W F
R827 1-249-433-11 CARBON 22K 5% 1/4W
R828 1-249-417-11 CARBON 1K 5% 1/4W F
R829 1-249-437-11 CARBON 47K 5% 1/4W
R830 1-249-417-11 CARBON 1K 5% 1/4W F
R841 1-249-441-11 CARBON 100K 5% 1/4W
R842 1-249-441-11 CARBON 100K 5% 1/4W
R843 1-249-441-11 CARBON 100K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-247-825-11 CARBON 560 5% 1/4W
R854 1-249-438-11 CARBON 56K 5% 1/4W
0R855 1-234-499-21 ENCAPSULATED COMPONENT
R856 1-249-417-11 CARBON 1K 5% 1/4W F
R857 1-249-431-11 CARBON 15K 5% 1/4W
R858 1-249-441-11 CARBON 100K 5% 1/4W
R859 1-260-076-11 CARBON 10 5% 1/2W
R871 1-260-319-51 CARBON 180 5% 1/2W
R872 1-260-319-51 CARBON 180 5% 1/2W
R873 1-260-319-51 CARBON 180 5% 1/2W
R874 1-260-319-51 CARBON 180 5% 1/2W
R875 1-249-402-11 CARBON 56 5% 1/4W F
R876 1-249-417-11 CARBON 1K 5% 1/4W F
R877 1-249-433-11 CARBON 22K 5% 1/4W
R878 1-249-417-11 CARBON 1K 5% 1/4W F
R879 1-249-441-11 CARBON 100K 5% 1/4W
R880 1-247-903-00 CARBON 1M 5% 1/4W
R881 1-215-889-00 METAL OXIDE 330 5% 2W
R883 1-249-437-11 CARBON 47K 5% 1/4W
R885 1-249-429-11 CARBON 10K 5% 1/4W
R887 1-249-441-11 CARBON 100K 5% 1/4W
R889 1-249-429-11 CARBON 10K 5% 1/4W
R891 1-249-438-11 CARBON 56K 5% 1/4W
R892 1-249-439-11 CARBON 68K 5% 1/4W
R894 1-249-429-11 CARBON 10K 5% 1/4W
R895 1-249-429-11 CARBON 10K 5% 1/4W
R896 1-249-435-11 CARBON 33K 5% 1/4W
R897 1-249-433-11 CARBON 22K 5% 1/4W
R898 1-249-425-11 CARBON 4.7K 5% 1/4W F
R900 1-249-425-11 CARBON 4.7K 5% 1/4W F
R961 1-215-870-11 METAL OXIDE 1.5K 5% 1W
R962 1-215-870-11 METAL OXIDE 1.5K 5% 1W
0R963 1-212-881-11 FUSIBLE 100 5% 1/4W
0R964 1-212-881-11 FUSIBLE 100 5% 1/4W
R965 1-249-431-11 CARBON 15K 5% 1/4W
R966 1-249-435-11 CARBON 33K 5% 1/4W
R967 1-249-435-11 CARBON 33K 5% 1/4W
0R968 1-202-972-61 FUSIBLE 1 5% 1/4W
R969 1-249-439-11 CARBON 68K 5% 1/4W
R970 1-249-433-11 CARBON 22K 5% 1/4W
R971 1-249-421-11 CARBON 2.2K 5% 1/4W F
R972 1-249-433-11 CARBON 22K 5% 1/4W
R973 1-249-421-11 CARBON 2.2K 5% 1/4W F
R974 1-249-429-11 CARBON 10K 5% 1/4W
R982 1-249-427-11 CARBON 6.8K 5% 1/4W F
R983 1-249-421-11 CARBON 2.2K 5% 1/4W F
R984 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY881 1-755-168-11 RELAY
< THERMISTOR(POSITIVE) >
THP841 1-807-796-11 THERMISTOR
< TERMINAL >
TM801 1-694-677-11 TERMINAL BOARD (4P) (FRONT SPEAKER)
TM802 1-694-677-11 TERMINAL BOARD (4P) (SURROUND
SPEAKER)
**************************************************************
1-676-971-11 HP BOARD
*********
< CAPACITOR >
C1691 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1692 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1693 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN1691 1-785-316-51 PIN, CONNECTOR (STRAIGHT) 4P
< TERMINAL >
* EPT1691 1-537-738-21 TERMINAL, EARTH
< JACK >
J1691 1-793-829-11 JACK, HEADPHONE (PHONES)
**************************************************************
1-671-505-11 IN SW BOARD
************
< CONNECTOR >
* CN710 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S703 1-771-218-11 SWITCH, MICRO (MID IN SW)
S704 1-771-218-11 SWITCH, MICRO (IN SW)
**************************************************************
1-671-502-11 INT/COUNT SW BOARD
*******************
S705 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY) (INIT SW)
S706 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY) (COUNT
SW)
**************************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
HP
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
